2015 Hot Selling, 1.3 Megapixel IR Mini Cctv AHD Camera
US$ 15.5 - 21.8
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ISEC or OEM
Model Number:
IC-LBW20-DA7 series
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Resolution Suveillance Camera,Cheap 720P or 960P Surveillance AHD Camera, High Definition Camera De SurverillanceUS$ 31.5 - 31.5MOQ: 1 Piece -
2016 Hot: Waterproof 2.8-12mm Manual 720p/960p hd Cctv CameraNegotiableMOQ: 1 Piece
-
Chinese CCTV Camera Manufacturer 720p/960p Waterproof Full hd Ahd CameraNegotiableMOQ: 1 Piece
-
2016 Hot Selling: hd Cmos 720p/960p Cctv Camera,AHD,IP, CVI,TVI 1mp/1.3mp Analog CameraNegotiableMOQ: 1 Piece
-
New Product Guangzhou Factory 1.3mp 960h Metal Dome IR AHD CameraUS$ 31.5 - 31.5MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
ISEC or OEM
Model Number
IC-LBW20-DA7 series
Type
Analog Camera
Style
Bullet Camera
Sensor
Other, CMOS, 1MP/1.3MP CMOS sensor
Technology
Infrared
Special Features
Waterproof / Weatherproof
Product Description
2015 hot selling, 1.3 Megapixel IR mini cctv AHD Camera
Features:
Mini Waterproof IR AHD camera
3.6mm board lens
2.8/6mm lens are optional
24pcs Ø5mm IR LEDs
IR distance:20m
0 lux with IR on
waterproof:IP66
84(W) x 69(D)x 55(H) mm
Specification:
| Model | IC-LBW20-DA7 | IC-LBW20-DA7B | IC-LBW20-DA7C |
IC-LBW20-DA7D |
| Item | AHD camera | |||
| Device Type | 1/4" 1MP CMOS Sensor, OV9712+NVP2431H, OSD | 1/3" 1.3MP CMOS Sensor, IMX238+NVP2431H, OSD | 1/4" 1MP CMOS Sensor, AR0141A+NVP2431H, OSD | 1/3" 1.3MP CMOS Sensor, AP0130+NVP2431H, OSD |
| Size | 1/4' | 1/3' | 1/4' | 1/3' |
| Day and Night | Yes | |||
| Min.Scene Illumination | 0.01lux(IR ON) | |||
| Infrared sensitivity | Support | |||
| IR Filter | IR-CUT | |||
| IR-led | Yes | |||
| IR distance | 20M | |||
| Electronic shutter | 1/5-1/15,000 /S | |||
| Lens | ||||
| Lens | 3.6mm board lens |
|||
| Focus | fixed Lens | |||
| Aperture | Fixed Aperture F1.2 | |||
| Video | ||||
| Compression | H.264 Main Profile/Baseline | |||
| Picture Resolution |
1MP (720P):1280x720@25fps |
1.3MP (960P):1280×960@25fps |
1MP (720P):1280x720@25fps |
1.3MP (960P):1280×960@25fps |
| Steam flow | Support dual stream | |||
| Bit Rate | 128-8192kbps | |||
| Bit Rate Type | CBR/VBR | |||
| S/N Ratio | >50DB | |||
| Image enhancement | Auto White Balance,Backlight compensation,Brightness,Contrast,Saturation adjusted | |||
| Subtitles input | Support channel name, date/time | |||
| Flip Config | Up/down, Left/right | |||
| Audio | Support the microphone input and LINE OUT, support two-way voice intercom equipment | |||
| Audio input/ output | one channel audio input, one channel audio output | |||
| Audio Compression | G.711/G.726 | |||
| Alarm input/output | one channel alarm input, one channel alarm output | |||
| Alarm processing | The control center to monitor, Go to PTZ preset pos, Send E-mail, Log record,SD card storage etc. | |||
| Network | ||||
| Protocal | HTTP,TCP/IP,UDP, SMTP, DDNS, DNS, SNTP,DHCP, FTP, RTP, RTSP,UPNP,ONVIF | |||
| Ethernet | Ethernet (10/100 Base-T),RJ-45 connector | |||
| Safety | IP address filtering,User level password protection,The user access log | |||
| Software | ||||
| WEB Browser | Microsoft Internet Explorer 6.0 and above,google, firefox etc. | |||
| Mobile Phone | Support iPhone, Android, Bit rate: 32K – 512K adjustable, Frame rate: 6–12 fps | |||
| Software Management | CMS and the devices Compatible with ONVIF | |||
| Remote Access | DDNS, Software, P2P | |||
| Power Comsumption | DC 12V, Module power consumption is less than 2W | |||
| Temperature | -20°~60°C | |||
| Humidity | -10~85% |
|||
Some functions of AHD camera:
