Bullet AHD Camera 1.0MP/1.3MP/2MP with IR Distance 20 meters cctv security camera
♦ Product type: Bullet AHD Camera 1.0MP with IR Distance 20 meters cctv security camera
♦ 720p/960p 1080p optional,
♦ Innovative Double Program Technology. One program for daytime, bring out the real color of objects; another program for nighttime, bring out clear picture at IR LED working, improve 40% sensitivity than a normal IR camera.
♦ IP66, Fully weatherproof and dustproof.
♦ 3.6mm fixed Lens,2.8mm/6mm lens for optional .
♦ Wall mount installation high quality security bullet cameras.
Detail Pictures
Specifications about Bullet AHD Camera 1.0MP with IR Distance 20 meters cctv security camera
| Model NO. | IC-LBW20-DA7G | IC-LBW20-DA7I | IC-LBW20-DA9B | IC-LBW20-DA9A | IC-LBW20-DA2A | IC-LBW20-DA2B | IC-LBW20-DA2C |
| VIDEO | |||||||
| Image Device | 1/4" 1MP H42 | 1/3" 1.3MP SC1035 | 1/3" 1.3MP IMX225 | 1/2.7" 2MP OV2710 | 1/2.9" 2MP IMX322 | 1/2.7 2MP PC2210 | |
| Sensor Type | CMOS | ||||||
| DSP | NVP2432H | HD8901 | NVP2431H | NVP2441H | NVP6021 | ||
| TV System | PAL/NTSC | ||||||
| Image Resolution | 1280(H)x720(V) , 1MP | 1280(H)x960(V) , 1.3MP | 1920(H)x1080(V) , 2MP | ||||
| Scanning System | Progressive Scan | ||||||
| Synchronization | Internal | ||||||
| Frame rate | PAL: 25fps,720P(1280x720); NTSC: 30fps,720P(1280x720) | PAL: 25fps,960P(1280x960); NTSC: 30fps,960P(1280x960) | PAL:25fps,1080P(1920x1080); NTSC:30fps,1080(1920x1080) | ||||
| Min. Illumination | Color: 1.0lux,F1.2; B/W: 0 Lux(IR ON) | Color: 0.1lux,F1.2; B/W: 0 Lux(IR ON) | |||||
| S/N Ratio | >50dB | ||||||
| Video Output | AHD(720P) | AHD(720P)/CVI(720P)/TVI(720P)/CVBS(960H) | AHD(960P) / CVBS (960H) | AHD(1080P) / CVBS (960H) | |||
| LENS | |||||||
| Focal Length | 3.6mm board lens | ||||||
| IR-CUT | 3MP IR filter cut | ||||||
| OPERATIONAL(OSD MENU) | |||||||
| Day & Night | NO | NO | AUTO /COLOR /B/W /EXT | NO | |||
| D-WDR | NO | NO | OFF/ON/AUTO | NO | |||
| Noise Reduction | NO | NO | 3DNR :OFF/Low / Middle / High | NO | |||
| Back Light | NO | NO | BLC/HSBLC/OFF | NO | |||
| Auto Gain Control | NO | OFF/ON(HIGH/MID/LOW) | 0~15 Adjustable | NO | |||
| Defog | NO | NO | OFF / AUTO | NO | |||
| Motion Dectection | NO | NO | ON(Motion area and sensitivity can be settled)/OFF | NO | |||
| Sense Up | NO | NO | OFF/AUTO(2X~30X Adjustable) | NO | |||
| Pricacy Mask | NO | OFF/ON(4 Masks) | OFF/ON(8 Masks) | NO | |||
| Electronic Shutter Speed | NO | AUTO/MANUAL(1/60 ~ 1/100,000sec) | 2X~30X/AUTO/1/50 ~ 1/50,000sec | NO | |||
| White Balance | NO | ATW1/ATW2/ATW3 | ATW/AWC->SET/INDOOR/OUTDOOR/MANUAL/AWB | NO | |||
| Brightness | NO | LOW/MIDDEL/HIGH | 0~100 Adjustable | NO | |||
| Mirror | NO | NO | OFF/MIRROR/V-FLIP/ROTATE | NO | |||
| Sharpness | NO | 0~100 Adjustable | OFF/AUTO(Level,Start AGC and End AGC can be settled) | NO | |||
| OSD Language | NO | English/Chinese | English, Chinese, Spanish, German, French, Russian, Portuguese, Italian, Polska, Nederland, Turkish | NO | |||
| General | |||||||
| Infrared LED | 24pcs Ø5mm IR LEDs | ||||||
| IR Distance | about 20 Meters | ||||||
| Infrared Spectrum | 850nm | ||||||
| Input Current | 400mA | ||||||
| Adapter Requirement | DC 12V, 1A | ||||||
| Water-proof | IP66 | ||||||
| MECHANICAL | |||||||
| Color | White, Silver optional | ||||||
| Bracket | Available | ||||||
| Dimensions | 84(W) x 69(D)x 55(H) mm | ||||||
| Net Weight | 0.45kg/pc | ||||||
| ENVIRONMENTAL | |||||||
| Operation Temperature | -10℃ ~ +50℃ RH95% Max | ||||||
| Storage Temperature | -20℃ ~ +60℃ RH95% Max | ||||||
Packing
♦ Package: 50pcs / carton
♦ Carton size: 42.4*40.4*42.4 cm
Shipping
| Why choose US? |
♦ China Factory Security Manufacturer. 9 Years experience, Supply Cctv CCD / CMOS camera, HD-SDI camera, IP camera, Mini Camera, PTZ camera, Cctv DVR, NVR, Cable, BNC, Balun, Adaptor etc.
♦ Quality Control. Strictly tested before packing, More than 12 hours aging before sending,Ce,Fcc,Rohs.
♦ Competitive Price. Factory price (EXW), More favorable price for big quantity.
♦ Technical support. Provide all-around technical support and counselling all the time.
♦ MOQ. 1 piece. Suggest our clients test sample first before bulk order.
Shenzhen Isec Tchnologies Co., Ltd is a leading manufacturer of security dome cameras, cctv camera, analog cameras, IP cameras, HD-SDI cameras, DVR, NVR, and accessories in Shenzhen, China.
