Product Details
Place of Origin: | China | Brand Name: | SVC | Model Number: | PT 6~20K |
Phase: | Other, 6~10K single phase, 10~20K three phase | Protection: | Short Circuit | Output Voltage: | 220v |
Type: | On-line | Application: | Other, Suitable for all electrical equipments |
Product Description
6Kva~20Kva, High Frequency Online UPS, CPU Control, Rack and Tower
Introduce: |
PT6-20K are new generation UPS to meet users' incrasing demand for safe, reliable, efficient and stable solution of back up power, they provide the best power to the loads. |
Field of application: |
Suitable for all electrical equipments, especially for the key equipment, such as communication systems and computer networks, for electric power demanding environment of equipment it offer more flexible, reliable power supply. |
Performance characteristics: |
1, High frequency control, wide input voltage range and strong ability to adapt to the environment; 2, Stable output voltage(pure sine wave output), can be applied to all electrical equipment; 3, LED display with simple content; 4, Application of advanced DSP digital control technology, make the UPS more stable performance of superior quality; 5, Zero transfer time; 6, Intelligent battery management, prolonging the service life of the battery; 7. Complete protection function, high reliability; 8, Can be used with generators, wide input voltage and frequency range to effectively isolate the bad power generated by the generator, provide clean, safe,stable power supply to load; 9, With RS-232/USB computer communication interface can carry out automatic archiving, shutdown and monitor management status of UPS asintelligent monitoring function. |
Model: | 6KVA 10KVA 20KVA |
Input voltage range: | 110V: 80~138VAC 220V: 80~300VAC |
Output voltage range: | 110V: 110±2%VAC 220V: 220±2%VAC |
Output frequency: | 46~54Hz Same as AC(AC mode) 110V: 50 or 60±0.2Hz (DC mode)/220V: 50±0.2Hz (DC mode) |
Wave form: | Sine wave |
Transfer time: | 0 ms |
Backup time: | >4'/12' >3'/8' |
QTY & capacity of battery: | 12V7.5AH*16pcs 12V7.5AH*16pcs External batteries |
Charging period: | Depends on the battries connected |
RJ45/11 & USB: | 110V: USB+RS232 220V: RJ45/11+RS232, Intelling slot selectable |
Net weight (kg): | 110V:9.5---35 220V:7.5---33 |
Unit dimension (mm): | 220*145*405 195*330*455 |
Environment of performance: | Temperature 0°C~40°C, Humidity 20%~90% |
