FM-520 Packing machine system:1. Fully automatical packing system
2. High speed with high accuracy
3. Stable quality
FM-520 Packing machine system :
Main Features:
- Servo driven film transport system.
- Servo-driven, intermittent motion end seal jaws.
- User-friendly PLC and touch screen operation interface allowing for multilingual operation and access restriction features.
- Comprehensive synchronisation for date printer and feeding systems.
- Simple and fast bag size changeover with one-piece forming sets.
- Jam detection/ alert to prevent product jam between the sealing jaws
- Photocell for centring printing.
- Completely outfitted with Stainless Steel in order to provide durability as well as sanitation.
- Every unit comes equipped with hot foil printer
The various packaging applications include
- Free Flow Powders: Sugar, Salt, Pepper, Spices, Flour, Semolina, Milk powder, various sorts of powders, etc. [non-food: detergents, plaster, talc, chemical additives]
- Granules & Seeds: Coffee beans, Cocoa, Rice, Sesame, Seeds, Small Granules etc.
- Dry, Frozen & Processed Foods: Snack foods [popcorn/chips], Cereal & Health Foods,
- Confectionary, Biscuits & Bakery, Pasta, Grated Cheese, Nuts, Dried fruits and vegetables, Frozen Vegetables, Dried Mushrooms, Pet Food.
- Fresh Foods: Fresh Produce
- Non Food: Medium- Nuts, Small metal/plastic items, Bolts, Washers, Auto, Electrical and Plumbing Parts etc.
3.2 Technical Parameters
Basic technical specifications
FOCUS FM-520
Bag size: L=100-390mm, W=75-245mm
Packing range: 15-1000g (depending on the materials)
Fill roll: Laminated Film [OPP/CPP, OPP/PE, MST/PE, PET/PE, N/PE, OPP/EVA, EVA/PE]
Thickness: 0.04-0.08mm
Max. output/ speed: 40-100 bag/min depending on bag length, output of used dosing device, product character, dosing size and required dosing accuracy.
Electricity Consumption: 220 V, 50 Hz, 3.5KW
Air Consumption: 6kg/cm, 0.25m3/min
Weight: 600kg
Machine dimensions: 1400mm x 1500mm x 2100mm (L x W x H)
Available dosing systems
- Auger doser,
- (Volumetric) Cup filler,
- Multihead weigher,
- Linear weighers,
- Liquid doser.
Usable types of packaging materials
The FM-520 machine is equipped with thermal jaws enabling the use of all standard thermal weldable materials, such as:
- Laminated Al foil with polyethylene
- Paper laminated with polyethylene
- Polypropylene film
- As well as a number of special films [e.g. monolayer film]
Specification & Index
Bag type |
Standard pillow bags |
Standards |
Laminated film, such as OPP/CPP, OPP/PE, MST/PE. PET/PE, N/PE, OPP/EVA, EVA/PE |
Film width |
Max. 500 mm |
Bag size |
Min. width 75 mm. x Min. Length 100 mm. Max. width 245 mm. x Max. Length 390 mm. |
