Non-gravity Powder blending machine
1. Intro
Horizontal Non-gravity Powder Mixer is an advanced machine characterizing in high efficiency, high degree of homogeneity, high intensity, low energy consumption, low polution.
2. Application
a. The machine is with wide application range for mixing powder-powder, powder-granule, especially suitable for materials with big specific gravity difference or particle size difference.
b. The machine is widely used in industries such as pharmaceutical,food, feedstuff, chemical fertilizer,sand paste etc..
3. Main Features
a. It consists of three parts: Transmission part, Agitator and Twin U-shape Cylinder. The transmission part is the decelerator drives the agitator to run with lines of chain or gear driving. Agitator is two shaft paddles, the shafts reversely rotates at the same speed. The paddles on the shaft arranged with a special angle ensure the materials can splash to three directions including radial, loop, axial, forming a compound effect of cross circle, shearing mixing ect to achieve uniform mixing in the short time. The paddle can be two pieces and the alloy small blade can be easily replaced.
b. Twin U shape cylinder is with a door for cleaning. The exterior side can be with jacket for cooling or heating.
c. The discharging valve at the botton of the cylinder can be pneumatic one, electric one or manual one. And it can aso be designed with big door or small door for discharging according to production technology.
d.The machine can also be equipment with high-speed crashing device.It is needed when the material agglomerating. "Crushing Stick" with triangle tooth enclosure maintains high rotating speed of over 1400rpm, which smashes and depolymerizes the agglomerating materials in the material weightlessness area.
Reference Parameter
Model |
Motor |
Speed |
Capacity |
ShapeSize |
Weight |
SWZL-0.3 |
5.5 |
60 |
90-180 |
1500*850*950 |
880 |
SWZL-0.5 |
7.5 |
60 |
150-300 |
1550*1560*1150 |
1000 |
SWZL-1 |
11 |
43 |
300-600 |
1750*1750*1500 |
1500 |
SWZL-2 |
15 |
43 |
600-1200 |
2000*2500*1750 |
2500 |
SWZL-3 |
18.5 |
43 |
900-1800 |
2120*2650*1800 |
2900 |
SWZL-4 |
22 |
43 |
1200-2400 |
2450*2860*2300 |
4200 |
SWZL-6 |
37 |
35 |
1800-3600 |
2800*3000*2400 |
5800 |
SWZL-8 |
45 |
35 |
2400-4800 |
2800*3500*2550 |
6500 |
SWZL-10 |
55 |
29 |
3000-6000 |
3050*3650*2650 |
7500 |
SWZL-15 |
75 |
29 |
4500-9000 |
3200*4250*2850 |
9500 |
SWZL-20 |
90 |
22 |
6000-12000 |
3500*4650*3250 |
12000 |
Remarks:
*The above listed Max. processing capacity is calculated as per powder with specific gravity 1 as medium. The model selection should depend on the comprehensive factors such as materials viscosity, specific gravity etc.
*If works under special environment such as high temperature, high pressure, explosive, combustible, corrosive etc, correct data is required for correct model selection.
*The above data and picture is subject to change without notice. The accurate parameter should be subject to the object.
*Not all products are listed. For more, please contact with our sales engineer.
Custom designs are also available.
