3D Three Dimensional Powder Mixer
3D mixer, moves in 3D space to eliminate gravity segregation, stratification and aggregation caused by centrifugal effect, can deal with and mix a group of materials in rapidly and homogeneous. Taking into all-round performance of all kinds of mixers, 3D mixer is still an ideal mixer in nowadays and it is widely used in powder and particle mixing of pharmacy, chemical industry, food, light industry, mechanical, mining, national defense and other research and development institution.
Advantages:
3D mixer is with a large loading coefficient, up to 80~90%(other mixer is around 40~50%)
3D mixer is with a reasonable structure, easy to feeding and discharging.
High uniformity, short mixing time and low energy cost.
Mixer is made of stainless steel with nice appearance which is easy to clean and move.
Arc angle at all the corners which are polished by complete process and ensure no discharge residual, no mixing dead zone and easy to clean.
Model | Design Volume(L) | Max Loading Volume (L) | Capacity (kg) | Speed (rpm) | Power (kw) | Size | Weight (kg) | ||
Length | width | height | |||||||
SYH-1 | 1 | 0.8 | 0.5 | 15-30 | 0.12 | 500 | 600 | 600 | 50 |
SYH-5 | 5 | 4 | 2.4 | 15-30 | 0.25 | 600 | 1000 | 1000 | 150 |
SYH-15 | 15 | 12 | 7.5 | 15-30 | 0.37 | 700 | 1000 | 1000 | 200 |
SYH-50 | 50 | 40 | 25 | 0-8 | 1.1 | 1000 | 1400 | 1200 | 200 |
SYH-100 | 100 | 80 | 50 | 0-8 | 1.5 | 1200 | 1700 | 1500 | 500 |
SYH-200 | 200 | 160 | 100 | 0-8 | 2.2 | 1400 | 1800 | 1600 | 800 |
SYH-400 | 400 | 320 | 200 | 0-8 | 4 | 1800 | 2100 | 1950 | 1200 |
SYH-600 | 600 | 480 | 300 | 0-8 | 5.5 | 1900 | 2100 | 2250 | 1500 |
SYH-800 | 800 | 640 | 400 | 0-8 | 7.5 | 2200 | 2400 | 2300 | 2000 |
SYH-1000 | 1000 | 800 | 600 | 0-8 | 7.5 | 2250 | 2600 | 2600 | 2500 |
