Horizontal powder mixer machine 1000L with plough plow paddles and two flying knives
SIEHE Industry----Mixing Experts on Liquid and Powder!
Please feel free to contact us for more details:
Tel: +86 21 52913185 ext 113
Fax: +86 21 52912822
Email: sales04 at
Skype: siehe.sales10
1. Introduction:
Horizontal plough mixer is a Germany-technical late-model mixing equipment with high efficiency, high uniformity, high loading coefficient but low energy cost, low pollution and low crush. The agitator consists of multi-group of plough and fly-cutter which works together to mixing, smash, and dispersing materials. It is widely used in the mixing of powder=powder, powder-liquid and powder-particles, especially for the materials which may get aggregation during mixing. Liquid can be sprayed into powders. Vacuum system and drying system are also in option.
[Materials Specific Gravity]: ≤5g/cm³
[Capacity]: 50-30,000L
[Application]:Suitable for the mixing of pharmacy, food, pesticide, dye, chemical industry, plastic, lithium battery, ceramic, chemical fertilizer,rubber, mortar and etc.
[Materials]:Powders with fluidity whose specific gravity is up to 5g/cm³, liquid content is up to 20%, such as medical intermediate, flavoring, pesticide, reactive dyes, water-free dirt, lithium cobalt oxides battery material and etc.
2. Technical Parameters
Model | Power (kw) | Speed (rpm) | Fly-cutter Power&Q’ty (kw) | Fly-cutter speed(rpm) | Size (mm) | Capacity (L) | Size(mm) | Weight (kg) | ||
length | width | Heigth | ||||||||
SDH-0.05 | 2.2 | 0-150 | 1.5*1 | 2930 | Ø400*418 | 20-30 | 1000 | 700 | 1200 | 260 |
SDH-0.1 | 3 | 85 | 3*1 | 1440 | Ø400*800 | 30-60 | 1500 | 500 | 700 | 400 |
SDH-0.2 | 4 | 85 | 3*1 | 1440 | Ø500*1000 | 60-120 | 2000 | 600 | 900 | 600 |
SDH-0.5 | 7.5 | 62 | 3*2 | 1440 | Ø700*1200 | 150-300 | 2500 | 800 | 1200 | 1100 |
SDH-1 | 11 | 62 | 3*2 | 1440 | Ø900*1500 | 300-600 | 2700 | 1000 | 1450 | 1600 |
SDH-2 | 15 | 50 | 3*3 | 1440 | Ø1100*2000 | 600-1200 | 3300 | 1200 | 1700 | 2500 |
SDH-3 | 18.5 | 50 | 3*3 | 1440 | Ø1280*2250 | 900-1800 | 3800 | 1300 | 1950 | 2900 |
SDH-4 | 22 | 42 | 3*4 | 1440 | Ø1400*2700 | 1200-2400 | 4100 | 1400 | 2000 | 4000 |
SDH-5 | 30 | 42 | 3*4 | 1440 | Ø1500*3000 | 1500-3000 | 4200 | 1500 | 2000 | 4500 |
SDH-6 | 37 | 42 | 3*4 | 1440 | Ø1600*3200 | 1800-3600 | 4500 | 1700 | 2000 | 6000 |
SDH-8 | 45 | 33 | 3*5 | 1440 | Ø1650*3750 | 2400-4800 | 5000 | 1800 | 2200 | 7500 |
SDH-10 | 55 | 33 | 3*5 | 1440 | Ø1800*4000 | 3000-6000 | 6000 | 1900 | 2500 | 8500 |
SDH-15 | 75 | 26 | 3*6 | 1440 | Ø2000*4800 | 4500-9000 | 7000 | 2100 | 2800 | 9800 |
SDH-20 | 90 | 26 | 3*8 | 1440/2930 | Ø2200*5600 | 6000-12000 | 8000 | 2400 | 3000 | 13800 |
SDH-30 | 132 | 20 | 3*8 | 1440/2930 | Ø2300*7500 | 9000-18000 | 10000 | 2600 | 3500 | 18500 |
3. Inner structure
