Lab scale ribbon mixer
Introduction
Vertical conical ribbon mixer has advantages of good mixing performance, easy to discharge etc. Spray device, heating devices, lifting devices and drying devices are for option. Materials are lifted repeatedly, mist-spraying device uniformly sprays the liquid onto the solid materials, so that they will be well mixed. If this mixer is equipped with heating device then it will become an ideal drying machine.
Main Features
[Materials Specific Gravity]: ≤3g/cm³
[Capacity]: 50-15,000L
[Application]: Suitable for the mixing of pharmacy, food, pesticide, dyestuff, chemical industry, plastic, ceramic, chemical fertilizer, rubber, etc. (more information please click FREE CONSULTATION)
[Material]: Powder or particle whose specific gravity is up to 3g/cm³and with certain fluidity, liquid content is under 20%, such as medical intermediate, flavoring, pesticide, reactive dyes ,etc..
Technical Parameters
Model |
Power (kw) |
Thickness (mm) |
Capacity (kg) |
Size(mm) |
Weight (kg) |
|
Outer Diam |
Height |
|||||
SZXL-0.1 |
2.2 |
3 |
40-60 |
φ715 |
1570 |
220 |
SZXL -0.3 |
2.2 |
3 |
120-180 |
Φ920 |
1930 |
320 |
SZXL -0.5 |
4 |
3 |
200-300 |
Φ1140 |
2320 |
410 |
SZXL -1 |
7.5 |
3 |
400-600 |
Φ1480 |
2870 |
900 |
SZXL -1.5 |
11 |
4 |
600-900 |
φ1630 |
3140 |
1200 |
SZXL -2 |
11 |
5 |
800-1200 |
φ1800 |
3490 |
1300 |
SZXL -3 |
15 |
5 |
1200-1800 |
φ2000 |
3760 |
2400 |
SZXL -4 |
18.5 |
5 |
1600-2400 |
φ2250 |
4425 |
2500 |
SZXL -6 |
22 |
6 |
2400-3600 |
φ2550 |
4940 |
2850 |
SZXL -8 |
30 |
6 |
3200-4800 |
φ2780 |
5360 |
4250 |
SZXL -10 |
37 |
6 |
4000-6000 |
φ3000 |
5815 |
5200 |
SZXL-15 |
55 |
8 |
6000-9000 |
φ3450 |
6540 |
6300 |
Remarks:
*The above listed Max. processing capacity is calculated as per powder with specific gravity 1 as medium. The model selection should depend on the comprehensive factors such as materials viscosity, specific gravity etc.
*If works under special environment such as high temperature, high pressure, explosive, combustible, corrosive etc, correct data is required for correct model selection.
*The above data and picture is subject to change without notice. The accurate parameter should be subject to the object.
*Not all products are listed. For more information, please contact our sales engineer.
Custom designs are also available.
WHY US
- Stable and Easy to Maintain
Standard driving box ensures the stable operation and low maintenance cost. The agitator adopts cantilevered shaft structure, no contact between bearing end and materials.
Very small gap between agitator and cylinder wall in case of material adhesion.
- Rich Application Experience & Excellent Design Aptitude
Products are designed according to the characteristic of raw and finished materials and manufacturing process(i.e. Pressure requirement, proportion of solid and liquid) to meet the requirements in driving device, operability, sealing effect, etc. areas.
- Reliable Driving Device
Different driving devices in different capability, power and output speed are for option according to the materials feature, starting methods and mixing method.
Driving motor adopts SIEMENS, ABB, SEW, etc. international top-quality brands.
Reducers adopts R series umbrella gear reducer ( or K series spiral cone gear reducer) with advantages of high usage coefficient, large rated torque, high conveying rate, safe, long service life, low noisy, low risk of failure, easy to maintenance, etc..
- Nice Auxiliary Components
Auxiliary components are for option, such as: coil pipe steam heating jacket, honeycomb anti-pressure jacket, recycle-medium jacket, sampling valve, temperature detector, weighing system, dust collecting system, etc..
Various type can be customized, such as spraying type, ex. proof type, heating type, vacuum type, etc.
Equipment material can adopt carbon steel, SS304, SS316L, SS321, and also polyurethane lining or coated with high wear-resistant material.
Valves: plum blossom valve, butterfly valve, flap valve and ball valve are for option.
SIEHE Industry----Mixing Experts on Liquid and Powder!
Please feel free to contact us for more details:
Tel: +86 21 52913185 ext 113
Fax: +86 21 52912822
Email: sales04 at
Skype: siehe.sales10
