Concrete horizontal plow mixer
- 20 Set / Sets per Month
- Shanghai Port
- T/T
Product Details
Condition: | New | Mixer Type: | Other, coulter and cutter | Product Type: | Other, pharmaceutical, food, chemical industry, pottery, refractories, mortar |
Application: | Other, powder-powder, powder-slurry, powder-fiber material | Additional Capabilities: | Other, shearing, breaking, mixing | Place of Origin: | Shanghai, China |
Brand Name: | Siehe | Model Number: | SDH | Max. Loading Capacity: | 18000L |
Voltage: | 380V/50HZ(can be customized) | Power(W): | accordingly | Dimension(L*W*H): | accordingly |
Certification: | CE ISO BV SGS | Warranty: | 12 months, 12 months for free, life-long maintenance | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Concrete horizontal plow mixer
Concrete horizontal plow mixer is a Germany-technical late-model mixing equipment with high efficiency, high
uniformity, High loading coefficient but low energy cost, low pollution and low crush. The agitator consists of multi-
group of plough and fly-cutter which works together to mixing, smash, and dispersing materials. It is widely used in the
mixing of powder powder, powder-liquid and powder-particles, especially for the materials which may get aggregation
during mixing. Liquid can be sprayed into powders. Vacuum system and drying system are also in option.
[Materials Specific Gravity]: ≤5g/cm³
[Capacity]: 50-30,000L
[Materials]:Powders with fluidity whose specific gravity is up to 5g/cm³, liquid content is up to 20%, such as medical
intermediate, flavoring, pesticide, reactive dyes, water-free dirt, lithium cobalt oxides battery material and etc.
Rich Experience&Excellent Design Aptitude
Products are designed according to the characteristic of raw and finial products materials and manufacturing process(i.e.
Pressure requirement, proportion of solid and liquid) to meet the requirements in driving device, operability, leakproofness
and etc. areas. For instant, SIEHE industries developed high leakproofness, vacuumed and heating cylinder for battery
materials, the entireequipment heated in 400℃ for some special powder, special fly-cutter also be improved for environmental
engineering sludge treatment.
Reliable Driving Device
Different driving devices in various capacity, power and output speed are in option according to the materials, starting methods
and mixing method. Driving motor uses SIEMENS, ABB, SEW and etc international brands products, output torque can be output
by direct-combination, chain-wheel combination, hydraulic couplers and etc. Reducers uses K series spiral cone gear reducer
( or H series gear box reducer) with high usage coefficient, large rated torque, high conveying rate, safe, long service life, low
noisy, low risk of failure, easy to maintenance and etc advantages.
High Efficient Mixing Device
Plough adopts removable design which could adjust the gap between plough and chamber wall according to different fineness,
fluidity of the materials. Different surface treatment are for option to strengthen the plough in hardness or wear-resistance,
materials with high hardness also can be used to produce plough to meet the special operation conditions. Surface treatment
includes surface carburizing/nitriding, heat treatment, tungsten carbide spray and etc. Main shaft agitator: traditional plough,
serration plough, scraper plough; fly-cutter: multi-plate cross cutter, dual plate lotus cutter and other customized cutters.
Nice Assistant Component
Assistant components are in option, such as: coil steam heating jacket, honeycomb anti-pressure jacket, recycle-medium
jacket, real-time sampling valve, high speed fly-cutter, temperature detector, weighting system, dust collecting system, vacuum
drying system and etc.Spray and atomizing device are in option to spray little liquid which will mix the liquid into powders better.
Spraying system consists of pressure source, liquid storage tank, spray device. Cylinders can be designed in carbon steel,
SS304, SS316L, SS321, other harder alloy agitators can also be used on agitator. Lining of cylinder can be polyurethane or
spraying wear-resistant material.
Model | Power (kw) | Speed (rpm) | Fly cutter Power &Q’t (kw) | Fly cutter speed (rpm) | Size (mm) | Capacity (L) | Size (mm) | Weight (kg) | |||
length | width | Height | |||||||||
SDH-0.05 | 2.2 | 0-150 | 1.5*1 | 2930 | Ø400*418 | 20-30 | 1000 | 700 | 1200 | 260 | |
SDH-0.1 | 3 | 85 | 3*1 | 1440 | Ø400*800 | 30-60 | 1500 | 500 | 700 | 400 | |
SDH-0.2 | 4 | 85 | 3*1 | 1440 | Ø500*1000 | 60-120 | 2000 | 600 | 900 | 600 | |
SDH-0.5 | 7.5 | 62 | 3*2 | 1440 | Ø700*1200 | 150-300 | 2500 | 800 | 1200 | 1100 | |
SDH-1 | 11 | 62 | 3*2 | 1440 | Ø900*1500 | 300-600 | 2700 | 1000 | 1450 | 1600 | |
SDH-2 | 15 | 50 | 3*3 | 1440 | Ø1100*2000 | 600-1200 | 3300 | 1200 | 1700 | 2500 | |
SDH-3 | 18.5 | 50 | 3*3 | 1440 | Ø1280*2250 | 900-1800 | 3800 | 1300 | 1950 | 2900 | |
SDH-4 | 22 | 42 | 3*4 | 1440 | Ø1400*2700 | 1200-2400 | 4100 | 1400 | 2000 | 4000 | |
SDH-5 | 30 | 42 | 3*4 | 1440 | Ø1500*3000 | 1500-3000 | 4200 | 1500 | 2000 | 4500 | |
SDH-6 | 37 | 42 | 3*4 | 1440 | Ø1600*3200 | 1800-3600 | 4500 | 1700 | 2000 | 6000 | |
SDH-8 | 45 | 33 | 3*5 | 1440 | Ø1650*3750 | 2400-4800 | 5000 | 1800 | 2200 | 7500 | |
SDH-10 | 55 | 33 | 3*5 | 1440 | Ø1800*4000 | 3000-6000 | 6000 | 1900 | 2500 | 8500 | |
SDH-15 | 75 | 26 | 3*6 | 1440 | Ø2000*4800 | 4500-9000 | 7000 | 2100 | 2800 | 9800 | |
SDH-20 | 90 | 26 | 3*8 | 1440/2930 | Ø2200*5600 | 6000-12000 | 8000 | 2400 | 3000 | 13800 | |
SDH-30 | 132 | 20 | 3*8 | 1440/2930 | Ø2300*7500 | 9000-18000 | 10000 | 2600 | 3500 | 18500 |
Remarks:
*The above listed Max. processing capacity is calculated as per powder with specific gravity 1 as medium. The model selection
should depend on the comprehensive factors such as materials viscosity, specific gravity etc.
*If works under special environment such as high temperature, high pressure, explosive, combustible, corrosive etc, correct data
is required for correct model selection.
*The above data and picture is subject to change without notice. The accurate parameter should be subject to the object.
*Not all products are listed. For more information, please contact our sales engineer.
