Dual Planetary Mixer for High Viscosity Materials | Adhesive | Lithium Battery Slurry | Paste Etc.

Dual Planetary Mixer for High Viscosity Materials | Adhesive | Lithium Battery Slurry | Paste Etc. photo-1
Dual Planetary Mixer for High Viscosity Materials | Adhesive | Lithium Battery Slurry | Paste Etc. photo-2
Dual Planetary Mixer for High Viscosity Materials | Adhesive | Lithium Battery Slurry | Paste Etc. photo-3
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Mixer Type:
Planetary Mixer
Product Type:
Other, lithium battery slurry, toothpaste, cosmetics, adhesive
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Mixer Type Planetary Mixer
Product Type Other, lithium battery slurry, toothpaste, cosmetics, adhesive
Application Viscous Fluid
Additional Capabilities Other, dispersing, mixing, dissolving
Place of Origin Shanghai, China
Brand Name Siehe
Model Number SXJB
Max. Loading Capacity 1500L
Voltage 380V/50HZ(can be customized)
Power(W) accordingly
Dimension(L*W*H) accordingly
Certification CE, ISO,BV,SGS
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas



 Dual Planetary Mixer

Product Description



Dual Planetary Mixer is a new mixing machine with high performance, high efficiency, easy to clean and to maintain, which is innovated and

improved based on the introduced oversea advanced technology. The Dual agitators of this equipment rotate and at the same time revolve

around the axle, the agitators are divided by the viscosity and characteristics of the material, usually include paddle type, twist type, claw type,

 frame type etc., have good mixing, reacting, kneading, dissolving effect. The mixer is equipped with a separate set of scraper to scrape the

sides of the barrel and the mixing paddle can be added a scraper as well, so that it can scrape the bottom of the barrel and avoid dead corner

 to ensure the stability of the product. Dual Planetary Mixer adopts planetary gear wheel drive, there is a large output torque, suitable for high

temperature, high solids, high viscosity, and other difficult working conditions; this equipment is closed design, can be used with a vacuum

system to realize vacuum mixing, mixing bucket can be designed with a heating jacket, matching mold temperature controller, to realize

thermostatic mixing function, it’s the first choice of mixing equipment for the high-viscosity materials.
