Adhesive Dual Planetary Mixer:
Dual Planetary Mixer is a new mixing machine with high performance, high efficiency, easy to clean and to maintain, which is
innovated and improved based on the introduced oversea advanced technology. The Dual agitators of this equipment rotate
and at the same time revolve around the axle, the agitators are divided by the viscosity and characteristics of the material, usually
include paddle type, twist type, claw type, frame type etc., have good mixing, reacting, kneading, dissolving effect. The mixer
is equipped with a separate set of scraper to scrape the sides of the barrel and the mixing paddle can be added a scraper as
well, so that it can scrape the bottom of the barrel and avoid dead corner to ensure the stability of the product. Dual Planetary
Mixer adopts planetary gear wheel drive, there is a large output torque, suitable for high temperature, high solids, high viscosity,
and other difficult working conditions; this equipment is closed design, can be used with a vacuum system to realize vacuum
mixing, mixing bucket can be designed with a heating jacket, matching mold temperature controller, to realize thermostatic
mixing function, it’s the first choice of mixing equipment for the high-viscosity materials.
Main Features:
- It is suitable for dispersing and mixing solid-liquid, liquid-liquid. It is especially suitable for materials with high viscosity(such as adhesives, silicone, lithium slurry, silver & aluminum paste, etc.)
- The inner wall of the container is precisely lathed by big vertical lathe first and then mirror polished to ensure the movable scraper on the planetary frame can scrape all the materials on the container wall off when it is rotating, make sure no residue and reach better mixing effect.
- Vacuum is optional. It mix materials under vacuum condition to remove bubbles generated during mixing. And also it can charge materials through vacuum, which can reduce materials loss obviously and also guarantee the sanitation.
- The agitator in the chamber can do revolution and rotation at the same time, which enables the materials mixed thoroughly and also improving the mixing effieciency greatly.
- Tank can be with jacket for heating or cooling. Temperature control is optional.
Technical Parameter:
Model |
Working |
Container |
Motor |
Revolution |
Rotation |
SXJB-8 |
5 |
8 |
1.5 |
0-65 |
0-170 |
SXJB-15 |
12 |
15 |
2.2 |
0-65 |
0-170 |
SXJB-30 |
24 |
30 |
4 |
0-65 |
0-170 |
SXJB-50 |
40 |
50 |
5.5 |
0-65 |
0-170 |
SXJB-100 |
80 |
100 |
7.5 |
0-30 |
0-95 |
SXJB-200 |
160 |
200 |
11 | 0-30 | 0-95 |
| SXJB-300 | 240 | 300 | 15 | 0-30 | 0-95 |
| SXJB-500 | 400 | 500 | 22 | 0-30 | 0-65 |
| SXJB-800 | 640 | 800 | 30 | 0-30 | 0-65 |
| SXJB-1000 | 800 | 1000 | 37 | 0-30 | 0-65 |
| SXJB-1200 | 960 | 1200 | 45 | 0-30 | 0-65 |
| SXJB-1500 | 1200 | 1500 | 55 | 0-30 | 0-65 |
Remarks:
*The above listed Max. processing capacity is calculated as per water as medium. The model selection should depend on the comprehensive factors such as materials viscosity, specific gravity etc.
*If works under special environment such as high temperature, high pressure, explosive, combustible, corrosive etc, correct data is required for correct model selection.
*The above data and picture is subject to change without notice. The accurate parameter should be subject to the object.
*Not all products are listed. For more, please contact with our sales engineer.
