High Viscosity Dual Planetary Mixer machine
1. Intro
Dual Planetary Mixer is a new mixing machine with high performance, high efficiency, easy to clean and to maintain, which is innovated and improved based on the introduced oversea advanced technology. The Dual agitators of this equipment rotate and at the same time revolve around the axle, the agitators are divided by the viscosity and characteristics of the material, usually include paddle type, twist type, claw type, frame type etc., have good mixing, reacting, kneading, dissolving effect. The mixer is equipped with a separate set of scraper to scrape the sides of the barrel and the mixing paddle can be added a scraper as well, so that it can scrape the bottom of the barrel and avoid dead corner to ensure the stability of the product. Dual Planetary Mixer adopts planetary gear wheel drive, there is a large output torque, suitable for high temperature, high solids, high viscosity, and other difficult working conditions; this equipment is closed design, can be used with a vacuum system to realize vacuum mixing, mixing bucket can be designed with a heating jacket, matching mold temperature controller, to realize thermostatic mixing function, it’s the first choice of mixing equipment for the high-viscosity materials.
[Materials Viscosity]: ≤3,000,000 cps
[Production Capacity]: 5-2000L
[Application Industry]: Suitable for dispersing and mixing materials in industries such as coating, putty, adhesive, energy, electronics & electrical appliances, pharmaceuticals, cosmetics, food etc.
[Applicable Materials]: Various slurries with viscosity less than3,000,000cps, solid content under 90% such as battery paste, solder paste, ceramic paste, silicone inks, sealants, structural adhesives, soft cream, jam etc..
2. Reference Parameter
|
Model |
Working volume (L) |
Mixing power (kw) |
Revolving speed (rpm) |
Rotating speed (rpm) |
Scraper speed (rpm) |
Lifting mode |
Lift (mm) |
Hydraulic power (kw) |
Vacuum pump power (kw) |
Material |
|
SXJB-8 |
5 |
1.5 |
0-65 |
0-170 |
0-170 |
Hydraulic lifting |
300 |
0.75 |
0.37 |
Material contacting part SS304 |
|
SXJB-15 |
12 |
2.2 |
0-65 |
0-170 |
0-170 |
Hydraulic lifting |
350 |
0.75 |
0.55 |
Material contacting part SS304 |
|
SXJB-30 |
24 |
4 |
0-65 |
0-170 |
0-170 |
Hydraulic lifting |
500 |
1.1 |
1.5 |
Material contacting part SS304 |
|
SXJB-50 |
40 |
5.5 |
0-65 |
0-170 |
0-170 |
Hydraulic lifting |
500 |
1.1 |
1.5 |
Material contacting part SS304 |
|
SXJB-100 |
80 |
7.5 |
0-30 |
0-95 |
0-95 |
Hydraulic lifting |
650 |
1.5 |
2.2 |
Material contacting part SS304 |
|
SXJB-200 |
160 |
11 |
0-30 |
0-95 |
0-95 |
Hydraulic lifting |
750 |
2.2 |
2.2 |
Material contacting part SS304 |
|
SXJB-300 |
240 |
15 |
0-30 |
0-95 |
0-95 |
Hydraulic lifting |
900 |
3 |
4 |
Material contacting part SS304 |
|
SXJB-500 |
400 |
22 |
0-30 |
0-65 |
0-65 |
Hydraulic lifting |
1000 |
4 |
4 |
Material contacting part SS304 |
|
SXJB-800 |
640 |
30 |
0-30 |
0-65 |
0-65 |
Hydraulic lifting |
1100 |
4 |
5.5 |
Material contacting part SS304 |
|
SXJB-1000 |
800 |
37 |
0-30 |
0-65 |
0-65 |
Hydraulic lifting |
1200 |
5.5 |
7.5 |
Material contacting part SS304 |
|
SXJB-1200 |
960 |
45 |
0-30 |
0-65 |
0-65 |
Hydraulic lifting |
1300 |
5.5 |
11 |
Material contacting part SS304 |
|
SXJB-1500 |
1200 |
55 |
0-30 |
0-65 |
0-65 |
Hydraulic lifting |
1400 |
7.5 |
11 |
Material contacting part SS304 |
|
SXJB-2000 |
1600 |
75 |
0-30 |
0-65 |
0-65 |
Hydraulic lifting |
1500 |
11 |
15 |
|
|
*Capacity is tested based on the materials viscosity 200,000cps; The model selection shall be based on the data such as the materials viscosity, characteristic etc.
* If the working condition is high temperature, high pressure, flammable, explosive, corrosive or others, you must provide detailed data for our engineer to customize specially.
* If any change in the above table, subject shall prevail without notice.
* The table cannot include all products, please contact with our sales engineers for more information.
