Two shaft paint making machine
Two Shaft paint making machine is a product with dispersing, emulsifying, stirring functions developed on the basis of Single
optional mixing ways, conventional such as anchor, butterfly, frame, etc.; It has so strong adaptability that emulsion, dispersion
and mixing can be simultaneously realized, it can be customized by the different requirement of materials characteristic and
production process of the customer.
[Production Capacity]: 50-10,000L
[Applicable Materials]: Materials shall be with viscosity less than1,000,000cps, various slurry with solid content under 80%such as putty, printing ink, structural adhesive, anaerobic adhesive, suspension concentrate,etc..
Model |
Dispersing Power (kw) |
Dispersing Speed (rpm) |
Mixing Power (kw) |
Mixing Speed (rpm) |
Material |
Capacity (L) |
Hydraulic Power (kw) |
Lift (mm) |
SYZ-100 |
5.5 |
0-2880rpm |
2.2 |
0-85rpm |
SS304SS316L Stainless Steel |
≤80 |
1.1 |
700 |
SYZ-200 |
7.5 |
0-1450rpm |
4 |
0-85rpm |
SS304SS316L Stainless Steel |
≤160 |
1.5 |
800 |
SYZ-300 |
11 |
0-1450rpm |
7.5 |
0-61rpm |
SS304SS316L Stainless Steel |
≤240 |
1.5 |
900 |
SYZ-500 |
18.5 |
0-1450rpm |
11 |
0-61rpm |
SS304SS316L Stainless Steel |
≤400 |
2.2 |
1000 |
SYZ-800 |
30 |
0-1450rpm |
18.5 |
0-52rpm |
SS304SS316L Stainless Steel |
≤640 |
4 |
1100 |
SYZ-1000 |
37 |
0-1450rpm |
22 |
0-52rpm |
SS304SS316L Stainless Steel |
≤800 |
5.5 |
1200 |
SYZ-1300 |
45 |
0-1450rpm |
30 |
0-52rpm |
SS304SS316L Stainless Steel |
≤1000 |
5.5 |
1300 |
SYZ-1500 |
55 |
0-1450rpm |
37 |
0-41rpm |
SS304SS316L Stainless Steel |
≤1300 |
5.5 |
1400 |
SYZ-2000 |
75 |
0-1450rpm |
45 |
0-41rpm |
SS304SS316L Stainless Steel |
≤1600 |
7.5 |
1600 |
Remarks:
*The above listed Max. processing capacity is data designed in the reference of the viscosity values by 50,000cps;The calculating
of model selection should be based on the materials viscosity, characteristics etc.
*If works under special environment such as high temperature, high pressure, explosive, combustible, corrosive etc., detail data
is required for correct model selection.
*If any change in the above table, subject shall prevail without notice.
* The table cannot include all products, please contact with our sales engineers for more information.
