Four-Drum Liquid Filling Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Chemical, Other, Chemical, Machinery & Hardware, Coating, paint, printing ink, dye, pigment, adhesive, pesticide etc
Packaging Type:
Case
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Application
Chemical, Other, Chemical, Machinery & Hardware, Coating, paint, printing ink, dye, pigment, adhesive, pesticide etc
Packaging Type
Case
Packaging Material
Metal, Wood
Automatic Grade
Semi-Automatic
Driven Type
Electric
Voltage
380V, 220V, 240V, can be customized
Power
50/ 60 HZ
Place of Origin
Shanghai, China
Brand Name
SIEHE
Model Number
SGZ Series
Certification
CE, BV, ISO, SGS
After-sales Service Provided
Engineers available to service machinery overseas
Four-Drum Liquid Filling Machine
Product Description
Product Introduction:
- Automatic Filling Machine (Big Drum) consists of automatic input and output track system, material automatic convey system, filter system, automatic canned metering system,the air and ground operation path, control system. Implements the process of send into barrels automatically- automatic peeling - automatic seek the barrel mouth -automatic fall down - fast canned - slow accurate canned- automatically rise after canned - seek barrels mouth repeatedly - four barrel canned end - automatic send barrels out - new bucket automatically to the filling position.
- [Materials Viscosity]: ≤50,000 cps
- [Production Capacity]: 200-2,000kg
- [Application Industry]: Suitable for filling of materials in industries such as coating, ink, adhesive(glue), resin, chemical solvent, lubricant, pesticide, etc..
- [Applicable Materials]:Materials shall be with viscosity less than50,000cps, liquid or slurry with a certain liquidity such as edible oil, emulsion paint, color paste, industrial paint, curing agent, organic solvent, water-based ink, suspension concentrate, adhesive, detergent, etc..
Technical Parameter:
Model |
Power Supply |
Air Source (Mpa) |
Weighing (kg) |
Filling Speed (Can/h) |
Division Value (g) |
Material |
Scales Stage Size (mm) |
Filling Accuracy (g) |
Convey Rail(m) |
SQGZ-2000 |
220V,50HZ |
0.5 |
≤2000 |
40-60 |
200 |
Material Contact SS304 Stainless Steel |
1500*1500 |
≤±400 |
4.5+7.5 |
