Liquid Filling Machine
Introduction
Liquid Filling Machine is mainly used in industries such as coating, printing ink, paint, asphalt, glue, lubricant, petrochemical, fine chemical etc. It is suitable for filling liquid, ointment products.
Features
It adopts weighing type filling, so the filling accuracy is high and the filling will not be affected by different materials. It consists of two filling valves (Fast Fill and Slow Fill), which only can speed up filling speed but also increase filling accuracy. Its measure error is less than 10g per pail. Filling head adopts anti-drip device. The filled materials are without bubbles generated and with good effect. Material filling is automatically controlled. Pneumatic lid-clamping and lid-pressing device are optional.
Specification
- Power supply:220V,50/60Hz
- Filling speed: 160-300 Pails per hour
- Filling error:±0.2%
- Air consumption:Flux 0.1m3/h, pressure 0.4~0.6MPa
- Working temperature:0°C~40°C
- Convey roller:Unpowered roller, length of 1300mm
- Filling range:0.5-5L, 2-10L, 5-30L, 10-50L
- Materials:Wetted parts of SS304 or SS316
- Environment requirement:Explosive proof or Non explosive proof
- Capping device:Pneumatic lid-clamping device, Pneumatic lid-pressing device
Application
Coating, paint, printing ink, dye, pigment, adhesive, pesticide etc
Custom designs are also available
