Inline High-shear Emulsion pump(three stages) :
Inline High-shear Emulsion pump(three stage)is a continuous production type emulsifier with high efficiency. It processes
materials in continuous production or circulation of fine materials. The motor drives the rotor to rotate at high speed.
It narrows the particle size of Liquid-liquid and liquid solid materials through external mechanical force and distributes one
phase materials into another phase or many other phases evenly to realize good homogenizing, dispersing and emulsifying
result. As a result, the materials become stable emulsion. It can be equipped with materials transfer pump in front of it to make
it suitable for materials with mid-and high viscosity. The materials are thoroughly dispersed and sheared after going through it.
It is characterized in low noise and stable running, short transfer distance and low head.
[Materials Viscosity]: ≤20000 cps
[Applicable Materials]:Applicable for production process for solution, gel, suspension or emulsion of solid - liquid, liquid-
liquid materials such as juice, soup bases, milk production, tissue homogenate, cosmetics, surfactants, asphalt, emulsifier, oil
field chemicals etc.
Main Features
- Inline High-shear Emulsifier consists of one set of precision engineered stator and rotor inside the chamber.
- The strong centrifugal forces generated by the high speed rotation rotor absorb the materials into the working chamber of the rotor and stator from axial direction.
- All the materials dispersed, sheared and emulsified by the multi-layers Stator & Rotor and then ejected from the axial direction.
- Stable finished products with high quality are produced after one time circulation or times.
Model |
Power (kw) |
Capacity (m³/h) |
Speed (rpm) |
Inlet (mm) |
Outlet (mm) |
Materials |
SRB4/3 |
4 |
4 |
0-2930 |
DN40 |
DN32 |
304/316L |
SRB7.5/3 |
7.5 |
6 |
0-2930 |
DN50 |
DN40 |
304/316L |
SRB11/3 |
11 |
9 |
0-2930 |
DN50 |
DN50 |
304/316L |
SRB15/3 |
15 |
12 |
0-2930 |
DN65 |
DN50 |
304/316L |
SRB18.5/3 |
18.5 |
14 |
0-2930/1450 |
DN65 |
DN50 |
304/316L |
SRB22/3 |
22 |
18 |
0-2930/1450 |
DN80 |
DN65 |
304/316L |
SRB30/3 |
30 |
25 |
0-2930/1450 |
DN100 |
DN80 |
304/316L |
SRB37/3 |
37 |
30 |
0-2930/1450 |
DN100 |
DN100 |
304/316L |
SRB45/3 |
45 |
38 |
0-2930/1450 |
DN125 |
DN100 |
304/316L |
SRB55/3 |
55 |
47 |
0-2930/1450 |
DN125 |
DN100 |
304/316L |
SRB75/3 |
75 |
60 |
0-2930/1450 |
DN150 |
DN125 |
304/316L |
SRB90/3 |
90 |
70 |
0-1450 |
DN150 |
DN125 |
304/316L |
SRB-110/3 |
110 |
80 |
0-1450 |
DN150 |
DN125 |
304/316L |
SRB-160/3 |
160 |
100 |
0-1450 |
DN200 |
DN150 |
304/316L |
SRB-200/3 |
200 |
120 |
0-1450 |
DN200 |
DN150 |
304/316L |
Remarks:
* The capacity is data based on water as medium. The model selection shall be based on the data such as the materials
viscosity, density etc..
* Special operation condition, such as high temperature, high pressure, explosive, combustible and corrosive etc, details are
required for correct model selection.
* If any change in the above table, subject shall prevail without notice.
* The table cannot include all products, please contact with our sales engineers for more information.
