Lithium battery slurry paste planetary mixer
Dual Planetary Mixer is a new mixing machine with high performance, high efficiency, easy to clean and to maintain, which is innovated and improved based on the introduced oversea advanced technology.
High mixing efficiency, wide application
The Dual planetary mixer has two sets of agitators (can customize to be three sets)
revolving around the container axle and at the same time rotating at high speed, so that the materials are mixed rapidly under the action of strong shearing and kneading force. Various agitators (blade type, twist type, claw type, frame type etc) are in option based on materials with different viscosity and different specific gravity.
Safe and convenient operation
Adopt hydraulic cylinder as lifting actuators. Control the mixer up, stop and down through controlling the valve, simple operation with high stability; with barrel holding device for fixing the mixing tank rapidly to prevent any possible accident due to tank displacement. Interlock between the tank in place and machine running can be set to avoid mal-operation.
No residue on the wall, clean discharging
There is scraper on the planetary frame rotating together with the planetary frame, it clings to the container and scrape the materials on the wall off continuously. The container inner wall is precisely lathed and then mirror polished to ensure the scraper can scrape all materials sticking to the wall off without residue. The blades can also be equipped with scraper for scraping the materials at bottom to ensure without mixing dead corner and excellent mixing result. Finished products with stable quality is ensured.
Customized options
Different options are available such as explosion-proof type, closed type, heating type, with PLC intelligent control type, etc.. Material can be customized to be SS316L or special Spraying materials.
Model |
Working volume (L) |
Mixing power (kw) |
Revolving speed (rpm) |
Rotating speed (rpm) |
Scraper speed (rpm) |
Lifting mode |
Lift (mm) |
Hydraulic power (kw) |
SXJB-8 |
5 |
1.5 |
0-65 |
0-170 |
0-170 |
Hydraulic lifting |
300 |
0.75 |
SXJB-15 |
12 |
2.2 |
0-65 |
0-170 |
0-170 |
Hydraulic lifting |
350 |
0.75 |
SXJB-30 |
24 |
4 |
0-65 |
0-170 |
0-170 |
Hydraulic lifting |
500 |
1.1 |
SXJB-50 |
40 |
5.5 |
0-65 |
0-170 |
0-170 |
Hydraulic lifting |
500 |
1.1 |
SXJB-100 |
80 |
7.5 |
0-30 |
0-95 |
0-95 |
Hydraulic lifting |
650 |
1.5 |
SXJB-200 |
160 |
11 |
0-30 |
0-95 |
0-95 |
Hydraulic lifting |
750 |
2.2 |
SXJB-300 |
240 |
15 |
0-30 |
0-95 |
0-95 |
Hydraulic lifting |
900 |
3 |
SXJB-500 |
400 |
22 |
0-30 |
0-65 |
0-65 |
Hydraulic lifting |
1000 |
4 |
SXJB-800 |
640 |
30 |
0-30 |
0-65 |
0-65 |
Hydraulic lifting |
1100 |
4 |
SXJB-1000 |
800 |
37 |
0-30 |
0-65 |
0-65 |
Hydraulic lifting |
1200 |
5.5 |
SXJB-1200 |
960 |
45 |
0-30 |
0-65 |
0-65 |
Hydraulic lifting |
1300 |
5.5 |
SXJB-1500 |
1200 |
55 |
0-30 |
0-65 |
0-65 |
Hydraulic lifting |
1400 |
7.5 |
SXJB-2000 |
1600 |
75 |
0-30 |
0-65 |
0-65 |
Hydraulic lifting |
1500 |
11 |
Please contact with us or check our webisite for more detailed information.
