Home > Manufacturing & Processing Machinery > Mixing Equipment > Mixing Tank > Disperser for Make Paint

Disperser for Make Paint

Name: Disperser for Make Paint
Brand: Siehe
SKU: 100437501
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Mixer Type:

Other, dispersing disc

Product Type:

Other, coating,paint,ink,color paste,pigment,dyestuff,ceramic,etc.

Contact Supplier Request Quote Chat Now

Shanghai Siehe Mechanical & Electrical Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Mixer Type Other, dispersing disc

Product Type Other, coating,paint,ink,color paste,pigment,dyestuff,ceramic,etc.

Application Other, solid-liquid, liquid-liquid

Additional Capabilities Other, dispersing, mixing, dissolving

Place of Origin Shanghai, China

Brand Name Siehe

Model Number SFSY

Max. Loading Capacity 10000L

Voltage 380V/50HZ(can be customized)

Power(W) accordingly

Dimension(L*W*H) accordingly

Certification CE , ISO ,BV, SGS

Warranty 12 months

After-sales Service Provided Engineers available to service machinery overseas

disperser for make paint

Product Description

Main Features:

Hydraulic system, stable running, can lift up and down frequently.
Specially made hydraulic cylinder can realize oil-leakage free.
Non-explosion proof/ explosion proof configuration. Explosion proof grade can be customized.
Installation type: ground type/ platform type.
Cover: cover lifting with the headstock
With OMRON/EMERSON inverter.

Technical Parameters:

Model	Capacity (L)	Motor Power (kw)	Speed (rpm)	Disc Dia (mm)	Lifting (mm)	Hydraulic power (kw)	weight (kg)
SFSY-1.5	≤50	1.5	0-1450	150	600	0.55	400
SFSY-4	≤200	4	0-1450	200	800	0.55	600
SFSY-7.5	≤400	7.5	0-1450	230	900	0.55	800
SFSY-11	≤500	11	0-1450	250	900	0.55	1000
SFSY-15	≤700	15	0-1450	280	900	0.55	1100
SFSY-18.5	≤800	18.5	0-1450	300	1100	0.75	1300
SFSY-22	≤1000	22	0-1450	350	1100	0.75	1400
SFSY-30	≤1500	30	0-1450	400	1100	0.75	1500
SFSY-37	≤2000	37	0-1450	400	1600	1.1	1600
SFSY-45	≤2500	45	0-1450	450	1600	1.1	1900
SFSY-55	≤3000	55	0-1450	500	1600	1.1	2100
SFSY-75	≤4000	75	0-950	550	1800	2.2	2300
SFSY-90	≤6000	90	0-950	600	1800	2.2	2600
SFSY-110	≤8000	110	0-950	700	2100	3	3100
SFSY-132	≤10000	132	0-950	800	2300	3	3600

Remarks:

*The above listed Max. processing capacity is calculated as per water as medium. The model selection should depend on the comprehensive factors such as materials viscosity, specific gravity etc.

*If works under special environment such as high temperature, high pressure, explosive, combustible, corrosive etc, correct data is required for correct model selection.

*If any changes of the data and picture,no further notice is provided.Correct parameter is based on the real object provided.

*The sheet is not including all the products.To know more information,Pls feel free to contact our sales engineers.
