unsaturated polyester resins ABS resin alkyd resin reacting plant
- 30 Unit / Units per Month
- SHANGHAI
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Place of Origin: | Shanghai, China | Brand Name: | SIEHE | Model Number: | SSXX |
Condition: | New | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Unsaturated polyester resins ABS resin alkyd resin reacting plant
Resin is main raw materials for manufacturing plastics, in addition, it is also used for making paint, adhesion, insulating material, etc. . SIEHE provides design and manufacturing of complete production line from lab equipment to industry large-scale equipment.
SIEHE industry resin complete production line consists of batching kettle(droplet add kettle), reactor, vertical distillation column, vertical condenser, horizontal condenser, water knockout drum, overflow tank, pipelines, attenuation harmony kettle, filling machine, etc main devices equipped with heating device(hot oil/steam boiler), cooling system(refrigerating machine/cooling tower), vacuum system, etc to make unsaturated polyester resins, phenolic resin, epoxy resin, alkyd resin, ABS resin, etc. It is also available for making emulsion.
Working Principle:
Resin production process can be divided into the following part: raw materials metering, conveying and droplet addition, mixing and reacting (including heating , cooling, vacuumed, etc.), attenuation, cooling, filtering, filling, etc..
Batching and conveying: liquid batching adopts pumps, flow meter, powder batching adopts weighing system, air conveying and manual feeding, additive batching uses weighing method.
Mixing and reacting: mixing liquid to liquid or mixing powder into liquid though mixer in a certain temperature, pressure and time.
Heating: including heating source(oil heater, boiler, etc.), heating medium(oil, hot water, steam, etc.), heating jacket and equipped pipelines, valves, pumps, etc. Normally speaking, resin reactor takes use of outer half tube jacket to heat the reactor .
Cooing: including cooling source (cooling tower, cooling mechanical group, etc. ), cooling medium(water, salt water, etc. ), cooling medium storage pool, cooling tube jacket and equipped pipelines, valves, pumps, etc. Normally speaking, resin reactor takes use of outer half tube jacket to cool the reactor down.
Condensation and vacuum: heating steam can be recycled and reused by condenser(vacuum system are optional. ); condensation part includes distillation column, vertical condenser, horizontal condenser, water knockout drum, etc. Vacuum system includes vacuum pump, vacuum buffer tank, pipelines, valves, etc.
Filtering and filling: filter products after cooling, remove the sub-quality products, meter and pack the products(semi-auto filling machine and automatic filling machine are optional)
WHY US
Various Products: | SIEHE industry has rich experience in design and manufacturing resin equipment, therefore, SIEHE is able to design proper resin complete device for unsaturated polyester resins, phenolic resin, epoxy resin, alkyd resin, ABS resin emulsion, etc according to production process. |
Environmentally-friendly and Easy Operation | The entire complete plant including storage of raw materials, metering, addition, medium products and finial products conveying and filling are closed and automatic, which is environmentalfriendly and easy to operate. |
Intelligent production with High Stability | The entire production line can realize totally closed and automatic produce, all the touch screen, IPC, PLC, etc takes use of international famous products which can be programmed to realize industrial intelligent. All the site control system are designed in ex-proof. |
Non-standard | When resin viscosity is over 1,000,000cps, the requirement of mixing equipment will be very strict. SIEHE have rich experience of mixing high viscosity materials., especially for alkyd resin and acrylic resin. |
Temperature Control |
Temperature is one of the most important factor in resin reacting. SIEHE industry have rich design and manufacturing experience of temperature control during operation, we are confidence to control the error in ±1~2℃. |
