AU-01D Multifunctional Vet Anesthesia Machine

Name: AU-01D Multifunctional Vet Anesthesia Machine
Brand: Foinoe
SKU: 100428905
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Type:

Other, Anesthesia Equipments & Accessories

Brand Name:

Foinoe

Model Number:

AU-01D

Nanjing Foinoe Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai/Nanjing

Delivery Detail:

Delivery time depends on order quantity.

Type Other, Anesthesia Equipments & Accessories

Brand Name Foinoe

Model Number AU-01D

Place of Origin Jiangsu, China

AU-01D Multifunctional vet anesthesia machine

Pneumatically driven electronically controlled system .
Built-in ventilator , LCD display screen
With 1 patient circuit for adult (option: patient circuit for children).
5-tube flowmeters, O₂ & N₂O : 0.1L /Min~10L/Min;
Two vaporizes, Enflurane/Isoflurane/Sevoflurane;(Option : Halothane)
Oxygen Flush:	25~75L/Min
Respiration Mode :	IPPV, SIPPV, IMV,SIMV,PEEP,Manual, Sigh
Tidal Volume:	50-1500mL
I:E:	4:1,3:1,2:1,1:1,1:1.5; 1:2.0;1:2.5; 1:3,1:4
Respiration Frequency:	1-99bpm
PEEP:	1.5~10hPa
Ptr:	-10~10 hPa;
CO₂ absorber capacity :	1.5kg
IMV frequency :	1~12bpm,
O2 concentration:	21%~100%
Inspiratory Plateau	0-1S
Alarm parameter :	upper/lower limit of airway pressure, upper/lower limit of tidal volume , no tidal volume output ,apnea, upper/lower limit of Oxygen concentration, AC power malfunction, battery low power
Patient monitor :	8.4`` TFT large screen of high resolution
	ECG: 5-lead, gain:×2.5mm/mV, ×5.0mm/mV, ×10mm/mV, ×20mm/mV, analysis of ST segment and abnormal of heart rate (anti-defibrillate, anti-HF electrotome)
	Heart Rate: 20~250bpm
	RESP: Impedance, range: 0~100bpm
	SpO2: 0%~100%
	Pulse Rate: 20~250bpm
	NIBP: SBP, DBP, MBP, 10~270mmHg interval of automatic measurement 1~90min adjustable
	TEMP: 0~50ºC
	Alarm: Audio and visual alarm
	Tendency record 96 hours
