Digital Radiography medical equipment

Specifications

1. medical equipment digital radiology for direct digital x-ray images
2. CCD detector with high qualtiy image

 Angell-DR System    Main Function  Digital Detector     Blue Plus CCD  Scintillator     Cesium Iodide,Csl / Gd202S,GOS  Effective View Field     17″×17″/  17″×14″  Filling Factor     100%  Pixel Matrix     4k×4k,3kx3k  Pixel Size     108um (micron)/ /140um  Maximum Spac Resolution     4.6lp/mm/3.57lp/mm   Grayscale     14bits  Time to Take Image     ≤5 seconds  POD Technology     The size of the pixel can be doubled and the dose will be reduced  Power Supply Requirement  220V AC 10A 50Hz  In the case of product upgrade, the specification may be changed without notice.  Multi-function Automatic Stand  Imaging Part     all Purpose  Vertical Movement     43-183cm(center of the detector)  Maximum Speed     30 mm/sec  Detector Rotation     0-270 degree  Rotation Speed     2 degree/sec  Main Functions of the Angell-1600 Workstation  Imaging Part Indicator,Tissue Equalization,Filter Correction,Grayscale Transform  Window/Level Adjustment,Gamma Correction,ROI Equalization,Black/White Reversion  Image Segmentation, Mark,Enhancement,Smoothing  Sharpening,Compression,Magnification,Graphic/text report, Printing/typeset  Net Interface DICOM Standard Compatible  Upgrading Requirement  Angell-DR is suitable for digital upgrading of traditional screen/film x-ray imaging equipment  The basic requirement is an X-ray generator or digital gastroenterography   with high frequency and high voltage above 30KW,200mA

DIGITAL DETECTOR

Detector Technology

Blue Plus CCD

Scintillator

GdOS/Gsl

Effective View Field

17″×17″/ 14″×17″

Filling Factor

100%

Pixel Matrix

17 million pixels

Pixel Size

108um (micron)

Maximum Spatial Resolution

4.6lp/mm

Output Grayscale

14bits

Preview Image

Less than 5 seconds

Weight

50KG

GENERATOR

Power Requirement

3ph,380V

Output Power

50KW( HF Generator)

Max Output Voltage

150KV

Max Output Current

630MA

Range Of MAS

25-630mAs
