Home > Products > Dental microscope > LED dental operation microscope
LED dental operation microscope
- 5000 Piece / Pieces per Month
- Nanjing /Shanghai
- Credit Card
You May Like
Product Details
| Type | Other, Cleaning & Filling Teeth Equipments | Brand Name | FoiNoe | |
| Model Number | DM-L | Place of Origin | Jiangsu, China |
Product Description
LED dental operation microscope
1.With full range of spare parts, and flexible combination, it is suitable for examination and surgeries in several kinds of fields.
2. High-contrast image, great depth of field and excellent stereo effect.
3. 6-step magnification changer, different working distance for options.
4.LED light source with patent integration module.
5.LED light source with long service life and low energy consumption.
6.Continous illuminationn control.
It fits for AC 90-240V and automatic identification.
Specifications:
SPECIFICATIONS DM-L100 plus DM-L100E/N plus DM-L100D plus | ||||
MICROSCOPE | ||||
Binoculars | 45° inclined f’=160mm | Straight f’=160 mm | 45 ° inclined f’=160 mm | |
Objective | f’=190-210 mm | f’=220-350 mm | f’=220-350mm | |
Eyepiece | 12.5x, high-eyepoint, wide angular, pupil exit distance 21mm | |||
Diopter adjustment | -5D to + 5D | |||
Magnification changer | 6 steps: 0.3x, 0.5x,0.8x 1.2x, 2.0x, 3.0x | |||
Total magnifications | 2.4x, 4x, 6x 9.6x,16x, 24x | 2.4x, 4x, 6x 9.6x,16x, 24x | 2.4x, 4x, 6x 9.6x,16x, 24x | |
Visual field | 52mm- 8mm | 80 mm-12.5mm | 65mm-10mm | |
Interpupillary distance | 55mm to 75 mm | |||
Working distance | 190-210mm | 220-350 mm | 220mm-350mm | |
ILLUMINATION | ||||
Type | Coaxial illumination by optical light-guide system | |||
Cold light source | LED lamp, 3V/10W | |||
Illumination control | 3steps | |||
Field of illumination | 55mm | |||
Power supply | AC 90-240 V | |||
Light intensity | 25,000 LUX | |||
Filter | Green, blue | Blue, green | Yellow, green | |
ARM, STAND | ||||
Type | Pantographic arm, floor stand | |||
Range | 1250mm | 1250mm | 1250mm | |
Rotation angle | 270° | |||
Elevation stroke | 400 mm | |||
Base size | 600 mm x 600 mm | |||
Weight | 85 KGS | |||
ACCESSORIES | ||||
Binoculars | 0-180° binoculars f’=170mm | |||
Beam splitter | Dismountable | |||
Adaptor for CCD | With iris diaphragm, f’=65 mm | |||
