Slit Lamp LYL-I

Name: Slit Lamp LYL-I
Brand: discretion
SKU: 100397937
Availability: InStock

Negotiable MOQ: 2 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

discretion

Place of Origin:

Model Number:

LYL-1

Wenzhou Jinzhou Group Foreign Trade Industries Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Brand Name discretion

Model Number LYL-1

Specifications

supply a full series high quality optical/ophthalmic/medical instrument,CE approvaled

Model LYL-I & LYL-ID
Total Magnification ;10X , 20X 4X ~ 18X
Objective magnification: 1X,2X0.4X ~ 1.8X(Zoom objective)
Working distance: 105mm 100mm
maging Pixels 0.47 million (795X596)				1.3M pix
Signal Output(for LYL-ID) Video Signals, USB Digital Signals
Analyze Software (for LYL-ID) PHMIAS 2003
Type of Microscopes
Converging Stereoscope, Inter-pupil Distance 55 to 75mm
Wide-angle eyepiece WF10X
Eyepiece magnification: 10X, linear field-of-view number:Φ2
Slit Width: 0 ~ 10mm Continuously Adjustable
Slit Height: 1 ~ 8mm Continuously Adjustable
Slit Angle: 360° Continuously Adjustable
Slit Inclination Angle Elevation 0 ~ 20°, Left and Right -6° ~ +6°
Slit horizontal Revolving Angle: Angle of Left and Right Revolving 30°
Light Spot Diameter: Φ0.2, Φ1, Φ2, Φ4, Φ6, Φ8, Φ10Continuously Adjustable
Filter: Heat Absorption, Grey, Redfree, Cobalt blue
Illumination Bulb: 12V30W Halogen Bulb
Input Voltage: 220V/50HZ (110V/60HZ)
Watch Bulb: Wine LED
Range of Rise or Drop of Slipway: 0 ~ 30mm
Move Range of Slipway
Left and Right: 105mm, Front and Back: 85mm
Fluctuate Move Range of Jaw Part: 50mm
