YZ20T9 OPERATION MICROSCOPE

YZ20T9 OPERATION MICROSCOPE thumbnail-1
YZ20T9 OPERATION MICROSCOPE photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
China
Model Number:
YZ20T9
Contact Supplier Request Quote Chat Now
Wenzhou Jinzhou Group Foreign Trade Industries Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Model Number YZ20T9

Specifications

supply a full series high quality optical/ophthalmic/medical instrument,CE/FDA approvaled

Characteristics
· Five-step magnifications for main microscope, three-step magnifications for assistant microscope; Fine focusing for assistant microscope keeps the same clearness as main microscope.
· Lens made of imported glass from Germany can reduce the optical aberration.
· X/Y movement can be automatically centered.
· Independent electrical box has automatical diagnosis function , which is very convenient for repair if necessary.

·Specification

Eyepiece Magnofication

12.5×/18B

Objective

200mm

Working Distance

190mm

Magnification for Main Microscope

4×,6×,10×,16×,25×

Magnification for Assistant Microscope

6×,10×,14×

Diameter of Field

Φ58mm,Φ38mm,Φ23mm,Φ14mm,Φ9mm

Adjustable Dioptor

±5D

Adjustable range for Pupil Distance

50mm~70mm

Illumination Source

12V/100W,Halogen Lamp

Illumination Type

6°+0°coaxial illumination and 26°oblique illumination which can be adjusted for slitting and the slitting width is adjustable.

Coaxial Illumination

≥30000lx

Oblique Illumination

≥15000lx

Reaching Range of Arm

1240mm

Adjustable Vertical Range

850mm~1350mm

Fine Focusing Speed and Range

≤2mm/s,≥50mm

Speed for X/Y and Range

≤2mm/s,50mm×50mm

Voltage

AC220V±10%/ 50Hz±1Hz,AC110V±10%/60Hz±1Hz

Power

330VA

Fuse

AC250V T4A,AC125V T8A

Electrical Safety Standard

Conform to Standard IEC 601-1.Class1Type B

Whole Packing Volume

0.786m3

Carton Number

5

Total Weight

213kg

· Optional Accessory
· Teaching Tube, Beam Splitter.
· 1/3” CCD camera, CCD Adaptor, Beam Splitter and relevant Cables.
