Gigabit Ethernet to STM-1 Optical Fiber Multiplexer

Gigabit Ethernet to STM-1 Optical Fiber Multiplexer thumbnail-1
Gigabit Ethernet to STM-1 Optical Fiber Multiplexer photo-1
US$ 960 - 1,620 MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
Baudcom Fiber Multiplexer
Model Number:
BD-EOS-GE/STM-1
Contact Supplier Request Quote Chat Now
Shanghai Baudcom Communication Device Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Fiber Multiplexer will be shipped from shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Brand Name Baudcom Fiber Multiplexer
Model Number BD-EOS-GE/STM-1
Gigabit Ethernet to STM-1 Optical Fiber Multiplexer


Overview

Gigabit Ethernet to STM-1 Optical Fiber Multiplexer (BD-EOS-GE/STM-4 in short hereafter) takes SDH technology as its core to provide access, convergence, transmission and management functions of TDM services and broadband IP services, and is a device for comprehensive access conversion in the applications of conventional telecommunicating services and broadband data services.

The Gigabit Ethernet to STM-1 Optical Fiber Multiplexer is an Ethernet over SDH interface conversion equipment supplied with two STM-4 optical interface, two electrical Ethernet and two Optical Ethernet interface.

The design of Gigabit Ethernet to STM-1 Optical Fiber Multiplexer complies with ITU-T and the relevant SDH specifications issued by Ministry of Information Industry, China.

The Gigabit Ethernet to STM-1 Optical Fiber Multiplexer carries the data services via the container in SDH, realizing the gigabit Ethernet over SDH.

The device applies 19" rack of 1U high, which can be placed on the desktop or installed in a cabinet of 2.2m or 2.6m high, and can directly drive the top-mounted aural-visual alarm unit.

The device can be powered by three power choice: AC 220V, DC -48V, and AC 220V with DC-48V backup.





Feature

  • Providing standard STM-4 optical interface that complying with G.707 standard;
  • Providing two electrical gigabit Ethernet ports and two optical gigabit Ethernet interface(optional);
  • Of excellent synchronous characteristics;
  • With DC-48V/AC220V optional for power supply;
  • Providing two optical STM-4 interface and two optical gigabit Ethernet interface;
  • Appling a rack with height 1U and width 19'', can be set on the desk or mounted in a cabinet or rack of height 2.2 m or 2.6 m;
  • The optical interface are SFP;
  • Supporting CLI management;
  • The device provide rich alarm indicator;









Technical Specifications

Ethernet Interface

 Interface type

10/100/1000M Base-Fx

Port specification

In accordance with IEEE802.3 10/100/1000M Base-Fx standard

Transmitting code speed

1000Mbps

 Type of connector

SC/FC/LC(can be chosed by customer)

Transmit distance

0-120Km



STM-4 Optical Interface

Optic interface velocity

Optic STM-4, G.957, Frame structure G.707

Interface code type

In accordance with the codes stipulated in G.957

Digital signals

In accordance with G.707 and G.958

Type of optical connector

LC/SC

Central wavelength

850 or 1310 or 1550 nm

Optional transmitting distance

0~40km (40~120km,to be customized) ( Single-Mode)

 0~2km (Multi-Mode)



Mechanical Specifications

Rack Mounting

Standard 19-inch DIN rack

Dimension

Desktop type : 440mm(L)*340mm(D)*43.5mm(H)



Management

Supporting CLI management;

Power Supply

Input AC/DC voltage

-48V DC ( nominal ) / AC also available

Range of input

-36V to -72V DC /90V~260VAC

Temperature

0 centi degree to 55 centi degree

Humidity

95% RH (non-condensing)

Cooling

Convection Cooling

Order information

BD-EOS-GE/STM-4

Gigabit Ethernet over STM-4 converter, two optical gigabit Ethernet;Two electrical gigabit Ethernet, two optical STM-4 port, power AC220V or DC48V



 Application diagram









Gigabit Ethernet to STM-1 Optical Fiber Multiplexer



                                      Front panel picture








Gigabit Ethernet to STM-1 Optical Fiber Multiplexer



Gigabit Ethernet to STM-1 Optical Fiber Multiplexer



Gigabit Ethernet to STM-1 Optical Fiber Multiplexer
