Ethernet Over Electronical STM-1 Converter
US$ 45 - 65
MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
Baudcom
Model Number:
BD-EOS-EE/AC
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Gigabit Ethernet Over 155M ConverterUS$ 1,150 - 1,350MOQ: 2 Units -
Ethernet Over SDH STM-1 EOS ConverterUS$ 300 - 460MOQ: 1 Unit
-
Ethernet Over STM-1 EOS ConverterUS$ 300 - 460MOQ: 1 Unit
-
SDH EOS Stm-1 to Ethernet ConverterUS$ 300 - 460MOQ: 1 Unit
-
155M Stm-1 to Ethernet Converter With SNMP ManagementUS$ 300 - 460MOQ: 1 Unit
Place of Origin
China
Brand Name
Baudcom
Model Number
BD-EOS-EE/AC
Overview:
Ethernet Over STM-1 Converter takes SDH technology as its core to provide access, convergence, transmission and management functions of TDM services and broadband IP services, and is a device for comprehensive access conversion in the applications of conventional telecommunicating services and broadband data services. The Ethernet Over STM-1 converter is an interface conversion equipment supplied with one STM-1 electronical interface and one electronical Ethernet interface. All daughter boards of the interfaces support online hot swap.
The design of the SDH converter complies with ITU-T and the relevant SDH specifications issued by Ministry of Information Industry, China.
The design of the SDH converter complies with ITU-T and the relevant SDH specifications issued by Ministry of Information Industry, China.
Features:
- Providing standard STM-1 interface that complying with G.664 standard;
- Providing an electric Ethernet interface;
- Of excellent synchronous characteristics;
- With DC-48V/AC220V optical for power supply.
- applies a rack with height 1U and width 19, can be set on the desk or mounted in a cabinet or rack of height 2.2 m or 2.6 m.
- Appling a rack with height 1U and width 19, can be set on the desk or mounted in a cabinet or rack of height 2.2 m or 2.6 m
Specification:
Ethernet Interface
Interface type 10/100M Base-Tx accordance with IEEE802.3 10/100M Base-Tx standard
Transmitting code speed 100Mbps
Type of connector RJ45
Type of connector RJ45
|
STM-1 Electronical Interface
Electric interface velocity 155520kbit/s (Electric STM-1,G.703,Frame structure G.707)
Interface code type In accordance with the codes stipulated in G.957
Digital signals In accordance with G.707 and G.958
Type of connector 75ohm coaxial cable
Power supply
working voltage range wide, good
anti-disturb and Isolation, work stable
option I DC-48V,range DC-36V~DC-72C
option II AC220V,range AC165V~AC240V
Power Consumption: <10 Watts
Environment condition
Operating temperature: -5C~+40 C
Storage temperature: -20 C~+55 C Relative temperature:85% (uncondensed) | ||||||||||
| ||||||||||
