Specifications
Both AC and DC available,cheap price in high quality manual lens meter,CE certificate|
Model NH-6 Lensmeter is used to measure the dioptres is spherical lens and cylinder lens,the axis of cylinder lens,the strength and the baseline direction of shuttle lens,It can also stamp the optical center of lens,the axis of cylinder lens and the base direction of shuttle lens. there are inner reading and outer reading two model. This instrument(Both AC and DC are permitted.Two 5# cells when DC) has clear readings and graduations as well as high objective precision and reliabilities except that it can be operated easily and conveniently.In addition,it has the compensation lens to correct the optical point center.AU the lenses and the made glasses can be measured by it,which,therefore,is a required and ideal measuring instrument for glasses manufacturers,glasses stores and ophthalmological hospitals. |
| MAIN PARAMETER |
1.Eyepiece focusing range:±5D
2.The top point dioptre measuring range:-25D~+25D
3.The minimum measuring square value:0.125D
4.The shuttle lens measuring range:10
5.The shuttle lens square value:1
6.The cylinder lens axial range:0-180°
7.The cylinder lens axial square value:1°
8.The maximum diameter of the measured lenses:100mm
9.The lighting:AC 220v/110v-6v DC 3v
