Product: stm1 to ethernet convertor
BD-EOS-FE-STM1 is stm1 to ethernet convertor (also called EOS or EoSDH) which deliver Ethernet services over SDH STM-1 transmission. The stm1 to ethernet convertor provides one or two STM-1 SDH optical interfaces and two 100M full-duplex Ethernet electrical ports, encapsulates Ethernet frame to SDH payload, providing fast and cost-effective Ethernet access for carriers and service providers. The standard STM-1 enables connection with any SDH multiplexers from other vendors to access backbone network or get simple point-to-point network directly.
The two Ethernet over STM-1 device can be managed by SNMP network management.
The stm1 to ethernet converter are available with AC power or DC power or mixed AC+DC power.
- Standard STM-1 optical interface, which provides 1 +1 protection, single fiber transmission, wavelength and light power of different interfaces and other options;
- Provides two Ethernet interfaces, and a 100M optical port, optical port can be independently Plug
- Ethernet mapping adopts GFP/VC-12 virtual concatenated technology; according with MSTP criterion;
- SNMP(10/100Base-T) network management port;
- Standard 19 inch 1 unit box;
- -48V DC or 220V AC power supply
- Substrate program on-line update supported.
Index |
Performance Parameter |
|
SDH Interface |
Max |
1~2 STM-1 optical interfaces (1+1 protection supported) |
Connector |
SC/PC |
|
Spec. |
S-1.1, L-1.1, L-1.2 |
|
Single fiber bi-directional interface can be optionally supported | ||
Service interface |
Ethernet port |
2*10/100Base-Tx
Comply with IEEE 802.3
|
Management |
Protocol |
SNMP |
Interface |
10Base-T |
|
Physical Dimension |
1U: 440x44x138 (mm) |
|
Power |
Supply |
-48V DC or 220V (110V) AC or dual power supply
+24VDC
|
Consumption |
<8w |
|
Environment |
Temperature |
0C-50C |
Humidity |
90 % |
|
FAQ
1.How can i get a sample ?
You need place sample order to us.We will arrange the sample production for you.
2.Could you do design for us?
Yes, we can do artwork including printing, logo etc. for you, if you provide us the content and tell us where to put.
3.How can we place order?
After we made agreement on the product' parameters, we will make proforma invoice for your confirmation.when we got your advance payment (deposit) we will arrange the production and delivery.
If you have your own ship forwarder, we will use your ship forwarder to delivery goods. if you don't have ship forwarder, then when the goods arrived at Destination port, you must find a ship forwarder help you clear the custom.
4.How about the shipping?
For small orders, we will send the goods by International Express like HK Fedex, DHL, TNT or UPS. usually it takes about 7work days to arrive.If big quantity we will ship by Ocean transportation, it takes one month to arrive. if urgnet, you can select shipping by Air, but freight charge will be more expensive.
5.what's your products' advantages ?
A. good quality and competetive prices.
B. Strictly quality control when producing.
C. Professional team work, from design, development, producing,assemble,packing and shipping.
D. Aftersale services, if there is quality problem, we will offer you replacement for defective quantity.
Packaging&Shipping
The devices will be well packaged by carton with Foam or other shock proof materials.
Certifications
| BD-EOS02-OO/A Ethernet over SDH,2 electrical ethernet port and 1 optical ethernet port over optical STM-1,power AC 220V |
| BD-EOS02-OO/D Ethernet over SDH,2 electrical ethernet port and 1 optical ethernet port over optical STM-1,power DC 48V |
| BD-EOS02-OO/A/P Ethernet over SDH,2 electrical ethernet port and 1 optical ethernet port over two optical STM-1,1+1 protection,power AC 220V |
| BD-EOS02-OO/D/P Ethernet over SDH,2 electrical ethernet port and 1 optical ethernet port over two optical STM-1,1+1 protection,power DC 48V |
The goods warranty time is THREE years,we will provide best support by TEL,email,remote control or engineers in field.
Your any questions will be responsed within 12hours!
