The single mode 20KM FC 16channel Video Multiplexer can simultaneously transmit 1-64 channels of 8-bit digitally encoded broadcast quality video / return or bidirectional data / unidirectional or bidirectional audio / Ethernet / Telephone / Dry contact over one multimode or single-mode optical fiber. These multiplexers are typically used in applications where the cameras have P/T/Z capabilities. Plug and Play design ensures the ease of installation and operation. Electronic and optical adjustments are never required. LED indicators are provided for instantly monitoring system status. Devices are available for either standalone or rack-mount installation ,which is suitable for different working environment .
- Directly compatible with NTSC, PAL, and SECAM CCTV camera systems and support RS-232, RS-422, and RS-485 data protocols
- Support any high-resolution video signal
- Automatic compatible PAL, NTSC and SECAM video system
- 1-4 channels audio (optional)
- 1-4 channels asynchoronus data (optional)
- 1 port 10/100Mbps ethernet (optional)
- Power supply and other parameter status indication, which can monitor the operation condition of system
- Support no-damage regenerative trunk of video
- Constant input optical power, and large dynamic range ,no Electrical or Optical Adjustments Required .
- Industry-grade of operating temperature from -40 to 85 degree , which is applied to the different working environment
- Hot-swap supportted
- Stand-alone type or card-type installed in 19 inch 2U or 4U rack-mount chassis.
Video interface
| Video | 16channels | |
| Video bandwidth | 8 MHz | |
Automatic compatible video system |
PAL,NTSC,SECAM
|
|
Video input / output impedance |
75 ohm(unbalance) |
|
Video signal-to-noise ratio |
≥67dB |
|
Differential gain |
(10%-90%APL)DG <1% ( typical value) |
|
Differential phase |
(10%-90%APL)DP <0.7 ( typical value) |
|
Video connector |
BNC |
|
Fiber-optic Specification |
F/O connector: FC/ST/SC
TX :Power:-8 ~ -3dBm Sensitivity : less than35dBm
RX:Power:-15 ~ -8dBm Sensitivity :-less than 24dBm
Transmission Distance :20KM (single mode) Operating Wavelength: TX1310/RX1550nm (Transmitter);TX1550/RX1310nm(Receiver)
|
||
Specification of custom-made options | |||
Data |
Connector: Terminal Blocks
Encoded type : RS485 / RS422 / RS232 / Manchester
Data rate : 0 - 400Kbps
BER: ≤10-9
|
||
Audio |
Connector: Terminal Blocks
Audio input / output impedance :600Ω(Balance/ unbalance)
Audio input / output voltage :2Vp-p ( typical value)
Audio input / output level :0dBm ( typical value)
Video bandwidth:10HZ~12KHZ
Audio digital encoded bandwidth :24bit
Audio signal-to-noise ratio: S/N≥95dB (weighted)
|
||
Telephone |
Connector: RJ11
Bandwidth :8KHZ
Features:Support call-showing function ;support H-F
Operating mode : Point to point hotline mode / FXS-FXO
|
||
Ethernet |
Connector: RJ45
Support mode : Half duplex or Full duplex
Standards:IEEE802.3
Data rate : 10M / 100Mbps
Bandwidth: 25M
|
||
Intelligent Transportation System
FAQ
1.How can i get a 16 channel video multiplexer sample ?
You need place sample order to us.We will arrange the sample production for you.
2.Could you do design for us?
Yes, we can do artwork including printing, logo etc. for you, if you provide us the content and tell us where to put.
3.How can we place order?
After we made agreement on the product' parameters, we will make proforma invoice for your confirmation.when we got your advance payment (deposit) we will arrange the production and delivery.
If you have your own ship forwarder, we will use your ship forwarder to delivery goods. if you don't have ship forwarder, then when the goods arrived at Destination port, you must find a ship forwarder help you clear the custom.
4.How about the shipping for 16 channel video multiplexer ?
For small orders, we will send the goods by International Express like HK Fedex, DHL, TNT or UPS. usually it takes about 7work days to arrive.If big quantity we will ship by Ocean transportation, it takes one month to arrive. if urgnet, you can select shipping by Air, but freight charge will be more expensive.
5.what's your products' advantages ?
A. good quality and competetive prices.
B. Strictly quality control when producing.
C. Professional team work, from design, development, producing,assemble,packing and shipping.
D. Aftersale services, if there is quality problem, we will offer you replacement for defective quantity.
Packaging&Shipping
The devices will be well packaged by carton with Foam or other shock proof materials.
Certifications
| BD-DV16P4P31ST | 16channel video fiber multiplexer,transmitter,4channel audio,3 channel RS485,one ethernet,single mode,dual fiber or WDM for option,SM20KM,AC220V | Request price |
| BD-DV16P4P31SR | 16channel video fiber multiplexer,receiver,4channel audio,3 channel RS485,one ethernet,single mode,dual fiber or WDM for option,SM20KM,AC220V | Request price |
| BD-DV16P0P00ST | 16channel positive video fiber multiplexer,transmitter,single mode,dual fiber or WDM for option,SM,20KM,AC220V | Request price |
| BD-DV16P0P00SR | 16channel positive video fiber multiplexer,receiver,single mode,dual fiber or WDM for option,SM,20KM,AC220V |
The goods warranty time is THREE years,we will provide best support by TEL,email,remote control or engineers in field.
