Home > Electrical & Electronics > Power Supply & Distribution > Power Adapter > Wall Mounted Usb Power Adapter

Wall Mounted Usb Power Adapter

Wall Mounted Usb Power Adapter thumbnail-3

Wall Mounted Usb Power Adapter thumbnail-4

Wall Mounted Usb Power Adapter thumbnail-5

Wall Mounted Usb Power Adapter thumbnail-6

US$ 3.5 - 4 MOQ: 1000 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

LYD

Model Number:

LYD1201000

Contact Supplier Request Quote Chat Now

Shenzhen Lianyunda Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name LYD

Model Number LYD1201000

Output Type DC

Connection Plug In

usb Power Adapter

Oupt power range	5v1a ,5.7v1a,9v1a,12v1a,17.5v0.7a,24v0.5a (also have those models for selection)
The adapter size	724331mm
The adapter weight	90g/pcs
Input Rated Voltage	100Vac~240Vac
Input Frequency Range	50Hz~60Hz
Input Current	less than 0.5A
Input Inrush Current	less than 50A
Efficiency	80%(MIN)at Rated Voltage
DC Output Voltage	3-36v (option)
DC Output Current	0-2A (option)
DC Output Power	5-12w (optional)
Leakage Current	less than 5mA
Standby power	less than 0.5w
DC connector	5.52.110mm (optional)
DC cable	1.5m 2464UL 22AWG cable (optional)
Ripple and Noise	less than 120Mv at full road with 20MHz bandwidth
Turn On Delay Time	less than 3S (AC:110V and full load)
Certificates	CE GS UL/CUL FCC ROHS SAA PSE TUVGS KC CLASS2 UL1310
Dielectric Voltage	A IEC320 three pin input---output(FG)3000Vac one minute
Safety protection	output voltage protection (150%-180% rated output current)
	output current protection (150%-180% rated output current)
	short current protection
Operating Temperature	-10°C - +45°C
Storage Temperature	-20°C - +40°C
Safety Standard	EN60950-1 UL60950-1 ESD (EN61000 3-3)
	CAS (60950 ITE/TE) FCC Part 15 subpart B Class B
	ISO 9001: 2008

Detailed description

Switch power supply

1)input voltage: AC 100-240V 50/60HZ
2)range voltage: AC 90-264V 47/63HZ

Safety Approvals

UL/CUL, PSE, GS, BS, CE, CB, FCC, and EK-Mark

Protections

1)over voltage protection: 120%min
2)over current protection: 120%min
3)over protection

4Short-circuit protection: automatic recovery

5Load regulation: ±5%

Environmental requirement

1)operating temperature: 0-40
2)storage temperature: -20-85
3)opera ting relative humidity:595%RH
4) Withstanding voltage: AC 3,000V (minimum), 5mA (maximum)

5Insulation resistance: DC 500V 100MΩ (minimum)

Brand name: LYD

Advantages

1. AC input power suitable for the world

2. Soft-start current can reduce the AC input impact efficiency

3. With short-circuit and overload protection

4. Compact size ,light weight

5. 100%full-load burning test

6. Installed with EMI filter ,minimum wave
