12V 2A Mains AC-DC Adaptor Power Supply for Satellite Receiver

Oupt power range

12v1.5a ,12v1a,10v1.3a,5v2a,5v2.5a (also have those models for selection)

The adapter size

85*48*32mm

The adapter weight

160g/pcs

Input Rated Voltage

100Vac~240Vac

Input Frequency Range

50Hz~60Hz

Input Current

less than 0.5A

Input Inrush Current

less than 50A

Efficiency

80%(MIN)at Rated Voltage

DC Output Voltage

12V± 5%  (option)

DC Output Current

2A    (option)

DC Output Power

24w    (optional)

Leakage Current

less than 5mA

Standby power

less than 0.5w

DC connector

5.5*2.1*10mm (optional)

DC cable

1.5m 2464UL 22AWG cable (optional)

Ripple and Noise

less than 120Mv at full road with 20MHz bandwidth

Turn On Delay Time

less than 3S  (AC:110V and full load)

Certificates

CE GS UL/CUL FCC ROHS SAA PSE TUVGS KC CLASS2 UL1310

Dielectric Voltage

A IEC320 three pin input---output(FG)3000Vac one minute

Safety protection

output voltage protection (150%-180% rated output current)

output current protection (150%-180% rated output current)

short current protection

Operating Temperature

-10°C - +45°C

Storage Temperature

 -20°C - +40°C

Safety Standard

GS 61347-2-13 EN55022

CAS (60950 ITE/TE)  FCC Part 15 subpart B Class B

ISO 9001: 2008
