AC/DC linear Adjustable DC output adapter 3~12V 0.5A Transformer for CCTV Cameras,

FOB Price

USD $1 - $3 / Piece

1000 Pieces(Min.Order)

Supply Ability 1000 Piece / Pieces per Month
Port shenzhen
Payment Terms:T/T

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	Guangdong, China	Brand Name:	LYD	Model Number:	LYD1200500
Output Power:	1 - 50W	Output Type:	Single	Input Voltage:	Other, AC100-240
Output Voltage:	12V	Output Frequency:	50/60 Hz	Output Current:	0.5A

Product Description

AC/DC linear Adjustable DC output adapter 3~12V 0.5A Transformer for CCTV Cameras

AC/DC linear Adjustable DC output adapter 3~12V 0.5A Transformer for CCTV Cameras (OEM/ODM) :

Safety:
Safeguard: class 2
IP: 20
Standards: UL/cUL, GS, BS, CE, SAA, C-Tick, CB, PSE, KC
Certificates: IEC/EN 60950/61558/61347 and UL1310, 60950
Energy efficiency: can be achieved CEC/EUP/ERP/MEPS

Applications:
Scope: lamp, electronic equipment, LED product, CCTV, communication, radio, motor-driven tool and appliances, Geyser, water pump, toy, safety protection, barbecue machine and others

Output power range	12V0. 5A (also have those models for selection)
Input Rated Voltage	100Vac~240Vac
Input Frequency Range	50Hz~60Hz
Input Current	less than 0.5A
Input Inrush Current	less than 50A
Efficiency	82%(MIN)at Rated Voltage
DC Output Voltage	12V± 5% (option)
DC Output Current	0.5A (option)
DC Output Power	6W (optional)
Leakage Current	less than 5mA
Standby power	less than 0.5w
DC connector	5.52.110mm (optional)5.52.510MM
DC cable	1.2m 2464 UL 18AWG cable (optional)
Ripple and Noise	less than 120Mv at full road with 20MHz bandwidth
Turn On Delay Time	less than 3S (AC:110V and full load)
Certificates	CE GS UL/CUL FCC ROHS SAA PSE TUVGS KC CLASS2 UL1310

Shipping & packing

Shipping :

UPS,DHL,Fedex,TNT,EMS(global Express),Shunfeng(Unite state,Korea,Japan, Southeast Asia)

Packing of 12v 0.5A:

white box+carton,carton size:74*26*38MM,108PCS/carton

12V 0.5A adapter :DC connector

How to contact us?if you have any requirement,send inquiry to me!

Kate

TEL:13651409973

QQ:2851331858

Skype:Kate_liu1993
