Dimming actuator RFDA-73M/RGB
Used to dim LEDs, an LED strip and RGB LED strip with power supply 12-24V DC control is performed with RF Control wireless transmitters or signal 0-10V/ 1-10V, or iNELS DAC converter iNELS
used to dim LEDs, an LED strip and RGB LED strip with power supply 12-24V DC
control is performed with RF Control wireless transmitters or signal 0-10V/ 1-10V, or iNELS DAC converter iNELS
The function (FUNC) selection switch enables setting of colored light scenes
upon switching off , the set level is stored in the memory, and when switched back on, it returns to the most recently set value
TIP for you
In newly manufactured product RFDA-73/RGB you can turn the potentiometer to the right side (excepting designated areas respectively printed) to test whether the RGB strip and connections are good.
If the LED strip lights everything is OK.
the load for individual channels is 3x5A, which in practice enablesdimming of approx. 60W = an 8m RGB LED strip
the supply voltage to the equipment and the LED strip must be the same. If the RFDA-73M/RGB is supplied by 12V DC, LED strip / source should also be supplied by 12V DC. The same applies for a supply voltage of 24V DC
programming is performed button PROG located on the front panel of the device
supplied with internal antenna SMA (M)
optional accessories: external antenna AN-E.
