Product Description
The Feature of Fast Delivery 3.5 Inch IIC Interface Resistive Touch Screen Panel for GPS as below:
1.Low cost solution, Low power consumption
2. Consistently accurate, fast touch response
3. Pressure sensitive, works with any stylus, Finger, gloved hand and stylus activation
4. Not affected by dirt, dust, water, or light
5. Affordable touch screen technology
6. Antiglare surface treatment
4 wire restistive touch screen technology:
Ckingway 4-Wire Resistive products are perfect for industry machine GPS System or portable products where compact size and low power draw is a priority – such as PDAs, GPSs, smart phones and other hand-held applications. Our pressure sensing 4-wire resistive touch screens are cost effective and allow for input versatility with bare or gloved fingers and any pointing device.
Backed by a one-year warranty and 5 million touches in a single location, Touch International’s 4-Wire resistive touch screens allow for ease of integration and use.
| Size | 3.5" inch |
| Structure | PET + Film + Film + Glass |
| Connector | Pin 4 plug connector |
| Thickness | 1.4 ± 0.15 mm |
| Touch Media | Finger, Touch Pen |
| Type | 4 Wire Restistive Touch screen |
| Ratio | 16:9 |
| Resolution | 4096*4096 |
| Response Time | ≤ 10 ms |
| Supply Voltage | 5V DC , 35 mA |
| Transparent | ≥ 78% |
| Screen Resistance | X:100-500Ω Y:200-1000Ω |
| Insulation Resistance | ≥20MΩ(10V DC) |
| Pressure | 50 - 150 g |
| Surface Hardness | 3H |
| Life Span |
> 1,000,000 time knocking ; ≥ 100,000 time in paddling |
| Operating Temperature | — 10℃ ~ +60℃ |
| Storage Temperature | — 20℃ ~ +70℃ |
| Storage Humidity | 20 ~ 85% RH (except congeal fog) |
| Custom Service | Available |
Fast Delivery 3.5 Inch IIC Interface Resistive Touch Screen Panel for GPS for Packing:
Anti-Static Foam+Paper Card+Ragged Bag+Carton
Fast Delivery 3.5 Inch IIC Interface Resistive Touch Screen Panel for GPS for Term of payment:
1.Full payment before delivery
2.Prepay 30% as the deposite,T/T 70% the balance before delivery
3.Prepay 50% as the deposite and mould fee ,T/T 50% the balance before delivery
4.Payment method can be nogotiated
