Easy installation 15.0HP titanium tube and shell heat exchanger for pool
- 10000 Set / Sets per Month
- NINGBO
- T/T Credit Card
You May Like
-
Hot sales titanium tube heat exchanger for swimming pool heat exchanger
Quality Choice
-
Titanium Shell & Tube Heat Exchanger,Titanium Tube condenser
-
swimming pool heat exchanger|PVC shell and titanium heat exchanger|titanium tube heat exchanger with PVC shell
-
Titanium Heat Exchanger in PVC Shell, small heat exchanger
-
Low Cost Cold Box Heat Exchanger, titanium pvc heat exchanger,aquarium water chiller
-
New Condition and CE,CCC Certification heat exchanger for siwimming pool
Product Details
| Condition | New | Place of Origin | Zhejiang, China | |
| Brand Name | WH | Model Number | WHC-15.0S | |
| Structure | Tube Heat Exchanger | Liquid Flow Rate | Optional | |
| Maximum Working Pressure | Tube side 4.5 Mpa | Weight | Optional | |
| Dimension(L*W*H) | Optional | Power(W) | 15.0HP | |
| Certification | Other, ISO9001:2008 | Warranty | 1 year |
1.Wooden cases 2.According to your requirement
Product Description
|
Main Products
|
Customer Feedback
|
Titanium tube and shell heat exchanger for pool
Work Condition:
2)Water side (Between the tube and PVC-U shell):Nature water,sea water,salt water ,swimming pool water or other corrosive solution.
Material:
1)Heat transfer Tube: Pure titanium tube.
2)Shell: PVC-U.
2)Pure titanium tube has super strong corrosion proof ability and high intensity.
3)The seamless titanium tube was tested by 4.0MPa pressure precise Halogen Leak Detection to make sure the tube is strong and not leakage .
4)The PVC-U shell was tested by 0.2Mpa water pressure to make sure the water system not leakage .
1) The data list is our suggested data, We can produce any capacity heat exchangers according customer requirement and design.
2) To guarantee constant inprovement of technology , the parameters shall be changed without further notice.
Specification:
Model | Specification | Type | Water Inlet/outlet size | Extermal Dimensions | ||||||
In (inch) | Out (inch) | A | B | C | D | E | ||||
WHC-0.5D | 0.5HP | 1.5KW | Single Loop | 1.0 | 1.0 | 410 | 200 | 320 | 70 | 270 |
WHC-1.0D | 1.0HP | 3.0KW | 1.0 | 1.0 | 450 | 200 | 360 | 70 | 310 | |
WHC-1.5D | 1.5HP | 4.5KW | 1.0 | 1.0 | 490 | 200 | 400 | 70 | 350 | |
WHC-2.0D | 2.0HP | 6.0KW | 1.0 | 1.0 | 590 | 200 | 500 | 70 | 450 | |
WHC-3.0D | 3.0HP | 9.0KW | 1.5 | 1.5 | 500 | 250 | 400 | 80 | 330 | |
WHC-5.0D | 5.0HP | 15.0KW | 1.5 | 1.5 | 600 | 250 | 500 | 80 | 430 | |
WHC-6.0D | 6.0HP | 18.0KW | 1.5 | 1.5 | 660 | 250 | 560 | 80 | 490 | |
WHC-8.0E | 8.0HP | 24.0KW | Double Loop | 1.5 | 1.5 | 850 | 250 | 750 | 80 | 680 |
WHC-10.0E | 10.0HP | 30.0KW | 2.0 | 2.0 | 1000 | 250 | 900 | 90 | 830 | |
WHC-12.0E | 12.0HP | 36.0KW | 2.0 | 2.0 | 1200 | 250 | 1100 | 90 | 1020 | |
WHC-15.0S | 15.0HP | 45.0KW | Triple Loop | 2.0 | 2.0 | 1000 | 315 | 900 | 90 | 830 |
WHC-20.0S | 20.0HP | 60.0KW | 2.5 | 2.5 | 1300 | 315 | 1200 | 100 | 1120 | |
Power(HP) Heating Capacity (kw) Unit:mm | ||||||||||
WH Factory is one of the largest Shell And Tube Heat Exchanger manufacturer in China ,who offer high quality heat exchanger with TA1 Titanium ,TA2 Titanium ,304 SS ,316 L ,copper and other materials, all products can be customized by request .
1). Professional manufacturer, ISO9001-2008
2). More than 6 years’ experiences of manufacturing.
3).Customized solutions and products
4).OEM/Small order accepted
5).Lead time 30 days
6).Tooling in house
7).High quality control
8).Competitive price
Our organisation is contributing huge patrons from the markets of China and other abroad countries such as Singapore, Middle-East, Africa, Malaysia, Europe, Denmark, America, Australia, UK, etc. Apart from these countries, we are also looking forward to entertain our more clients, by offering them our reliable products.
1:Before Service: All the process of Technical Production deportment and Strict Quality Control System. We also can provide the sample for your test quality.
2:Middle Service: Any question, pls feel free to tell us we will solve any doubt.
3:After Service: All the products problems, pls call us and E- mail us at any time, we will reply to you at the shortest time.
Payment Terms
Type of Payment: T/T100% payment in advanced, Paypal, Escrow, Western Union, L/C,etc.
Remark: If you have any question in payment, pls show us so that we will discuss.
Package:Standard export packing .
Shipping Terms:
1.For the sample order: we also use International Express freight: Such as: DHL, TNT, EMS, UPS and so on.
2.If your quantity is large, we will consider the Air or Sea Transport, all the detail terms we will discuss in the Contract.
Q1.Are you factory?
A.Yes,we are one of the largest corrosion resistant heat exchanger manufactory in China
Q2.May i get your product catalogue?
A.Sure, you are welcome to download the latest catalogue at our web /en,E-book , or contact us directly.
Q3.Are there any discount for the heat exchangers?
A.Yes. Bigger quantity will enjoy lower discount!
Q4.What is the MOQ?
A.We accept loose quantity order,mixed order,any trial orders.
Q5.What information needed if I want a quotation?
A .Please advise us the Type of heat exchangers, Material , Heat Exchanger Capacity, Water Flow, Water Temperature in and out ,Refrigrant Freon Type, Quantity, or any requirements in size.
Q6.Can we visit your company/factory before place the order?
A.Sure.Welcome anytime.
Q7.What's your contact way ?
A.
Att:Ms Joanna Zhang
QQ:1747660290
Wechat:qq1592268859
Email:wh(at)
Cell:86-15356255661
Tel:86-577-86198864
Skype:wzwuhuan
Shell And Tube Heat Exchanger
Company Profile
Wenzhou Wuhuan Refrigeration Accessories Factory is a professional manufacturer engaged in the research, development, production, sale and service of refrigeration equipment. We are located in Economic-Technical Development Zone of Wenzhou, Zhejiang and have convenient transportation access. Our main producets include : Shell & Tube Evaporators Pure Titanium Evaporators Titanium Guns Titanium Barrels Stainless Steel Evaporators Corrosion Resistant Evaporators Titanium Tube Heat Exchangers Profiled Titanium Tubes Other refrigeration accessories. Our products are widely used for cooling and heating in plating chillers, laser chillers, seafood machines, heat pump units, ice makers, marine air conditioning and other special industries. We produce high quality products, provide good after-sale services and establish a good reputation. To further meet the needs of a wide range of customers, we constantly develop new products distributed throughout China. Especially, our pure titanium evaporators are sold throughout mainland China, Hong Kong, Europe, America and Southeast Asia. Whether you are customers or friends, we thank you for trusting and supporting us! Now, we have enough confidence to let Wuhuan be full of vitality and competitiveness, having soaring development in 21st century. We want to contribute our efforts to the creation of a better future with you .
