56KW stainless steel shell and tube evaporator / heat exchanger for Anodic oxidation chiller
- 1000 Set / Sets per Month
- NINGBO
- T/T Credit Card
- 84KW Economical Triple system shell tube heat exchanger price PP shell stainless steel tube for Drinking Water Chiller
- 93KW High Quality Full stainless steel shell and tube heat exchanger,stainless steel heat exchanger,tube heat exchanger
- Tube Heat exchanger for air conditioner
- ISO Certification Shell And Tube Heat Exchanger, Heat Exchanger Equipment
- Copper tube Shell and tube type heat exchanger
- Sprial type shell and tube evaporator
Product Details
Condition: | New | Place of Origin: | Zhejiang, China | Brand Name: | WH |
Model Number: | WHB-12*2EKG | Structure: | Tube Heat Exchanger | Liquid Flow Rate: | 7.8 m*m*m/h |
Maximum Working Pressure: | Tube side 1.4 Mpa | Weight: | Optional | Dimension(L*W*H): | Optional |
Power(W): | 1HP~100HP | Certification: | Other, ISO9001:2008 | Warranty: | 1 year |
Packaging Details
1 set / wooden case
Product Description
Main Products
Customer Feedback
Shell and tube type evaporator
- Work Condition:
)Refrigerant side(In the tube): R22,R134a,R407c,R410a etc.
2)Water side (Between the tube and PP shell):Nature water,drink water etc .
Material:
1)Heat transfer Tube: 316L / SUS304.
2)Shell: PP
- Features:
1)Usually used for cooling.
2)Inner tube has super strong corrosion proof ability and high intensity.
3) The tube was tested by 1.62MPa pressure precise Halogen Leak Detection to make sure the tube is strong and not leakage .
4)The PP shell was tested by 0.5Mpa water pressure to make sure the water system not leakage .
- Application:
Shell and tube type evaporator are widely used for cooling and heating in certain fields of special industries, such as acid tank plating, aluminum oxidation, petrochemical industry, light industry, metallurgy, electric power, shipbuilding and marine environment etc.
- Notice:
1) The data list is our suggested data, We can produce any capacity heat exchangers according customer requirement and design.
2) To guarantee constant inprovement of technology , the parameters shall be changed without further notice.
- Design:
- Specification:
Model | W | Q | External Dimensions | Inlet/outlet Diameter | ||||||||||||
kw | Kcal/h | A | B | C | D | E | F | G | H | R | L | a1 | a2 | a3 | ||
WHB-5*2 EKG | 3.5 | 23.2 | 19.9 | 820 | 200 | 90 | 660 | 150 | 450 | 70 | 190 | 50 | 50 | 28 | 19 | 50 |
WHB-8*2 EKG | 4.5 | 37.2 | 34.6 | 1250 | 200 | 90 | 1090 | 200 | 820 | 70 | 190 | 50 | 50 | 28 | 19 | 63 |
WHB-10*2EKG | 6.0 | 46.5 | 39.9 | 1520 | 200 | 90 | 1360 | 250 | 1040 | 70 | 190 | 50 | 50 | 28 | 19 | 63 |
WHB-12*2EKG | 7.8 | 55.8 | 47.9 | 1125 | 250 | 90 | 965 | 150 | 745 | 70 | 230 | 57 | 57 | 28 | 19 | 63 |
WHB-15*2EKG | 9.0 | 69.7 | 59.9 | 1270 | 250 | 100 | 1090 | 150 | 870 | 70 | 250 | 62 | 62 | 38 | 28 | 63 |
WHB-20*2EKG | 12.4 | 93 | 79.9 | 1600 | 250 | 100 | 1420 | 300 | 1040 | 70 | 250 | 62 | 62 | 54 | 28 | 75 |
WHB-25*2EKG | 15.0 | 116.3 | 100 | 1965 | 250 | 100 | 1785 | 400 | 1300 | 70 | 250 | 62 | 62 | 54 | 28 | 75 |
To = 2 °C Tk = 40 °C Ti = 12 °C Tu = 7 °C Q rated cooling capacity (kw) W chilled water flow rate (m³ / h) Kcal/h: Kcal/h * 1000 Unit:mm |
- Working Condition
Shell Side | Tube Side | |
Design Pressure (Mpa) | 0.4 | 1.4 |
Max Pressure (Mpa) | 0.4 | 1.4 |
Test Pressure (Mpa) | 0.5 | 1.62 |
Design Tempeture ( °C ) | Normal | 38 |
Medium | H20 | R22/R404A/R134a... |
WH Factory is one of the largest Shell And Tube Heat Exchanger manufacturer in China ,who offer high quality heat exchanger with TA1 Titanium ,TA2 Titanium ,304 SS ,316 L ,copper and other materials, all products can be customized by request .
1). Professional manufacturer, ISO9001-2008
2). More than 6 years’ experiences of manufacturing.
3).Customized solutions and products
4).OEM/Small order accepted
5).Lead time 30 days
6).Tooling in house
7).High quality control
8).Competitive price
Our organisation is contributing huge patrons from the markets of China and other abroad countries such as Singapore, Middle-East, Africa, Malaysia, Europe, Denmark, America, Australia, UK, etc. Apart from these countries, we are also looking forward to entertain our more clients, by offering them our reliable products.
1:Before Service: All the process of Technical Production deportment and Strict Quality Control System. We also can provide the sample for your test quality.
2:Middle Service: Any question, pls feel free to tell us we will solve any doubt.
3:After Service: All the products problems, pls call us and E- mail us at any time, we will reply to you at the shortest time.
Payment Terms
Type of Payment: T/T100% payment in advanced, Paypal, Escrow, Western Union, L/C,etc.
Remark: If you have any question in payment, pls show us so that we will discuss.
Package:Standard export packing .
Shipping Terms:
1.For the sample order: we also use International Express freight: Such as: DHL, TNT, EMS, UPS and so on.
2.If your quantity is large, we will consider the Air or Sea Transport, all the detail terms we will discuss in the Contract.
Q1.Are you factory?
A.Yes,we are one of the largest corrosion resistant heat exchanger manufactory in China
Q2.May i get your product catalogue?
A.Sure, you are welcome to download the latest catalogue at our web /en,E-book , or contact us directly.
Q3.Are there any discount for the heat exchangers?
A.Yes. Bigger quantity will enjoy lower discount!
Q4.What is the MOQ?
A.We accept loose quantity order,mixed order,any trial orders.
Q5.What information needed if I want a quotation?
A .Please advise us the Type of heat exchangers, Material , Heat Exchanger Capacity, Water Flow, Water Temperature in and out ,Refrigrant Freon Type, Quantity, or any requirements in size.
Q6.Can we visit your company/factory before place the order?
A.Sure.Welcome anytime.
Q7.What's your contact way ?
A.
Att:Ms Joanna Zhang
QQ:1747660290
Wechat:qq1592268859
Email:wh(at)
Cell:86-15356255661
Tel:86-577-86198864
Skype:wzwuhuan
