Condition New
Place of Origin Zhejiang, China
Brand Name WH
Model Number WHC-80DKG
Structure Tube Heat Exchanger
Liquid Flow Rate 31.5m*m*m /h
Maximum Working Pressure Tube zide 1.8 Mpa , Shell side 0.6Mpa
Weight 143kg
Dimension(L*W*H) 670x480x2450mm
Power(W) 80HP
Certification Other, ISO9001:2008
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas



Product Description

High Quality 186KW corrosion resistant shell and tube heat exchanger for seawater heat exchanging More Economical

Work Condition:

1)Refrigerant side(In the tube): R22,R134a,R407c,R410a etc.

2)Water side (Between the tube and shell):Nature water,drink water,seawater etc .

Material:

1)Heat transfer Tube: 316L / SUS304 / Copper / Titanium

2)Shell: 316L / SUS304 / Csrbon steel / PP / PVC



Features:

1)Usually used for cooling / heating.

2)Pure titanium tube has super strong corrosion proof ability and high intensity.

3) The tube was tested by 1.62MPa pressure to make sure the tube is strong and not leakage .

4)The  shell was tested by 0.6Mpa water pressure to make sure the water system not leakage .



Application:

High Quality 186KW corrosion resistant shell and tube heat exchanger for seawater heat exchanging More Economical  is widely used for freezing industries,such as plating ,oxidation ,chemical industry,metallurgy,light industry,shipbuilding,heating, pharmaceutical,foodstuff etc, also for leather chiller, injection molding machine chiller, print chiller,PV shoe machine chiller and so on.



Notice:

1) The data list is our suggested data, We can produce any capacity heat exchangers according customer requirement and design.

2) To guarantee constant inprovement of technology , the parameters shall be changed without further notice.



Design:
