Condenser
- Work Condition:
1)Refrigerant side(In the shell): R22,R134a,R407c,R410a etc.
2)Water side (In the tube): Nature water,pure water,drink water or other liquid.
Material:
1)Heat transfer Tube: Copper, titanium
2)Shell: Carton steel.
- Features:
1)Usually used for heating .
2)Copper tube has super strong corrosion proof ability and high intensity.
3) The copper aloys tube was tested by 1.0 MPa pressure to make sure the tube is strong and not leakage .
4)The Carton steel shell was tested by 2.8Mpa water pressure to make sure the water system not leakage .
- Application:
WN series condenser designed as bigger shell , can be supporting the use of frozen and refrigerated .
- Notice:
1) The data list is our suggested data, We can produce any capacity heat exchangers according customer requirement and design.
2) To guarantee constant inprovement of technology , the parameters shall be changed without further notice.
- Design:
- Specification:
| Model | Q | M | External Dimensions (mm) | Connector size (mm) | N.W | ||||||||||||
| D | A | A1 | B | E | F | H | S | S1 | a | b | c(NPT) | d(NPT) | W | kg | |||
| WHT-WN3 | 11 | 2.3 | 140 | 850 | 750 | 500 | 200 | 150 | 265 | 80 | 80 | 16 | 12 | 3/8 | / | Rp1 | 30 |
| WHT-WN5 | 17.5 | 3.8 | 140 | 986 | 900 | 600 | 200 | 150 | 265 | 80 | 80 | 16 | 12 | 3/8 | / | Rp1 | 35 |
| WHT-WN6 | 21 | 4.5 | 168 | 986 | 900 | 600 | 200 | 150 | 295 | 80 | 80 | 16 | 12 | 3/8 | / | Rp1-1/2 | 45 |
| WHT-WN8 | 28 | 6 | 168 | 1086 | 1000 | 600 | 200 | 150 | 295 | 80 | 80 | 22 | 16 | 3/8 | / | Rp1-1/2 | 49 |
| WHT-WN10 | 35 | 7.7 | 168 | 1086 | 1000 | 600 | 200 | 150 | 295 | 80 | 80 | 22 | 16 | 3/8 | / | Rp1-1/2 | 52 |
| WHT-WN12 | 42 | 9 | 168 | 1288 | 1200 | 800 | 200 | 150 | 295 | 80 | 80 | 28 | 16 | 3/8 | / | Rp1-1/2 | 62 |
| WHT-WN15 | 53 | 12 | 219 | 1324 | 1200 | 800 | 250 | 200 | 345 | 100 | 100 | 28 | 22 | 3/8 | / | Rp2 | 92 |
| WHT-WN20 | 70 | 15 | 219 | 1324 | 1200 | 800 | 250 | 200 | 345 | 100 | 100 | 35 | 22 | 3/8 | / | Rp2 | 96 |
| WHT-WN25 | 87 | 19 | 219 | 1624 | 1500 | 1200 | 250 | 200 | 345 | 100 | 100 | 35 | 22 | 3/8 | / | Rp2 | 112 |
| WHT-WN35 | 122 | 26 | 273 | 1624 | 1500 | 1200 | 400 | 320 | 405 | 120 | 120 | 42 | 28 | 3/8 | / | Rp2-1/2 | 162 |
| WHT-WN40 | 140 | 30 | 273 | 1924 | 1800 | 1200 | 400 | 320 | 405 | 120 | 120 | 42 | 28 | 3/8 | 1/4 | Rp3 | 190 |
| WHT-WN45 | 158 | 34 | 273 | 1924 | 1800 | 1200 | 400 | 320 | 405 | 120 | 120 | 42 | 28 | 3/8 | 1/4 | Rp3 | 198 |
| WHT-WN50 | 175 | 38 | 273 | 1924 | 1800 | 1200 | 400 | 320 | 405 | 120 | 120 | 42 | 28 | 3/8 | 1/4 | Rp3 | 204 |
| WHT-WN55 | 192 | 41 | 273 | 2124 | 2000 | 1200 | 400 | 320 | 405 | 120 | 150 | 42 | 28 | 3/8 | 1/4 | Rp3 | 214 |
| WHT-WN60 | 210 | 45 | 273 | 2124 | 2000 | 1200 | 400 | 320 | 405 | 120 | 150 | 54 | 35 | 3/8 | 1/4 | Rp3 | 220 |
|
Refrigerant R22 Tc=40°C Ti=30°C Tu=35°C
Q heat exchanger capacity (kw)
M water flow rate (m³/h)
| |||||||||||||||||
