ZW-1/6-25 high pressure nitrogen boosting compressor
High pressure nitrogen boosting compressor
1. A nitrogen compressor is a device designed specially to compress hydrogen gas for storage.
2. Commercial nitrogen compressor are generally reciprocating types with the most common being guided piston/metal diaphragm
3. Nitrogen compressors are used to compressor the gas to enormous pressures, often in excess of 40,000PSI, so that it maybe stored in usable amounts.
4. The structure of the nitrogen compressor include 1 stage,2 stage,3 stage,4 stage to meet the client’s different demands.
A complete system of high pressure nitrogen boosting compressor
- The Pure nitrogen compressor
- The power conditioning Unit
- The cooling system
- The control and monitoring Unit and the safety system
Accessories of high pressure nitrogen boosting compressor
Crank-shaft, crank-case, cylinder, piston assembly, cross head, connecting bar cross head, piston ….
| Nitrogen Compressor Technical Parameter | |||||||
| Product type |
Medium |
Capacity (m³/min) |
Inlet Pressure (Mpa) |
Outlet Pressure (Mpa) |
Power (KW) |
Overall Dimension (mm) |
Weight (KG) |
| ZW-4.2/8-10 | Nitrogen | 4.2 | 0.8 | 1 | 30 | 1500x650x1350 | 1000 |
| ZW-0.8/6-30 | Nitrogen | 0.8 | 0.6 | 3 | 30 | 1600x750x1150 | 980 |
| ZW-0.5/6-16 | Nitrogen | 0.5 | 0.6 | 0.6 | 11 | 1550x700x900 | 540 |
| ZW-0.38/5.5-25 | Nitrogen | 0.38 | 0.55 | 2.5 | 11 | 1550x700x900 | 540 |
| ZW-0.31/6-25 | Nitrogen | 0.31 | 0.6 | 2.5 | 11 | 1450x650x1300 | 950 |
| ZW-0.34/8-30 | Nitrogen | 0.34 | 0.8 | 3 | 11 | 1550x700x900 | 480 |
| ZW-0.2/6-16 | Nitrogen | 0.2 | 0.6 | 1.6 | 4 | 1285x590x900 | 320 |
| ZW-0.25/4-15 | Nitrogen | 0.25 | 0.4 | 1.5 | 5.5 | 1285x590x900 | 400 |
| ZW-0.83/(2-5)-25 | Nitrogen | 0.83 | 0.2-0.5 | 2.5 | 22 | 1400x1196x940 | 1250 |
| ZW-0.83/6-16 | Nitrogen | 0.83 | 0.6 | 1.6 | 15 | 1305x700x900 | 480 |
| ZW-1/6-25 | Nitrogen | 1 | 0.6 | 2.5 | 30 | 1500x650x1500 | 700 |
| ZW-1/(4-6)-30 | Nitrogen | 1 | 0.4-0.6 | 3 | 30 | 1500x650x1350 | 950 |
| ZW-1.2/5-10 | Nitrogen | 1.2 | 0.5 | 1 | 15 | 1600x800x1150 | 840 |
| ZW-1.2/6-25 | Nitrogen | 1.2 | 0.6 | 2.5 | 30 | 1360x750x1150 | 900 |
| ZW-1.35/6.5-10 | Nitrogen | 1.35 | 6.5 | 1 | 11 | 1360x750x1150 | 765 |
| ZW-0.63/7-25 | Nitrogen | 0.63 | 0.7 | 2.5 | 18.5 | 1500x650x1550 | 1500 |
| ZW-0.5/6-25 | Nitrogen | 0.5 | 0.6 | 2.5 | 15 | 1600x750x1150 | 950 |
| ZW-0.42/(3-4)-14 | Nitrogen | 0.42 | 0.3-0.4 | 1.4 | 7.5 | 1300x590x900 | 400 |
| ZW-0.2/3-25 | Nitrogen | 0.2 | 0.3 | 2.5 | 5.5 | 1305x700x900 | 450 |
| ZW-0.45/0.8-7.5 | Nitrogen | 0.45 | 0.08 | 0.75 | 5.5 | 1280x590x900 | 750 |
Our nitrogen compressors are particularly suitable for all type of applications and depending on your requirement, we can provide the most suitable nitrogen compressor fitting your needs.
