Home > Packaging & Printing > Packing Machinery > Multi-Function Packing Machine > Semi-Automatic Close Door Manual Tie Horizontal Baler for Palm Silk Paper Carton
Semi-Automatic Close Door Manual Tie Horizontal Baler for Palm Silk Paper Carton
US$ 20,000 - 50,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, Machinery & Hardware
Packaging Type:
Cartons, Cans, Bottles, Bags, Film, Case
Payment & Shipping
Payment Methods:
Port of Shipment:
GUANGZHOU
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Semi-Automatic Horizontal Waste Baling MaterialUS$ 20,000 - 46,000MOQ: 1 Set -
Semi-Automatic Horizontal Baler for Plastic Bottle CansUS$ 18,000 - 30,000MOQ: 1 Set
-
Horizontal Hydraulic Manual Tied Plastic Packing MachineUS$ 24,000 - 50,000MOQ: 1 Set
-
Semi-Automatic Waste Paper Baling MachineUS$ 20,000 - 50,000MOQ: 1 Set
-
Semi-Automatic Horizontal PET Bottle Baling MachineUS$ 32,000 - 50,000MOQ: 1 Set
Condition
New
Application
Other, Machinery & Hardware
Packaging Type
Cartons, Cans, Bottles, Bags, Film, Case
Packaging Material
Plastic
Automatic Grade
Semi-Automatic
Driven Type
Hydraulic
Voltage
200/380/415V
Power
37KW
Place of Origin
Guangdong, China
Brand Name
GLOBAL GREEN
Model Number
HB-80
Weight
10000KG
Dimension(L*W*H)
6500*1460*2400
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
1.High Pressure for High Output2.Abandon Experience
3.PLC Control System
4.Bale Dimension and Density Adjustable
Semi-Automatic Close Door Manual Tie Horizontal Baler for Palm Silk Paper Carton
1. Hopper can be equipped or not.
2. Fed by conveyor or manually
3. Especially for bulk and hollow materials
Hopper of Machine
| MODEL | HB-50 | HB-80 | HB-100 | HB-150 | HB-200 |
| VOLTAGE | 200/380/415V | 200/380/415V | 200/380/415V | 200/380/415V | 200/380/415V |
| WORKING POWER | 17Mpa | 17Mpa | 17Mpa | 17Mpa | 17Mpa |
| MOTOR POWER | 15KW | 18.5KW | 22KW | 30KW | 37KW |
| CYCLINDER | 200mm | 220mm | 250mm | 320mm | 360mm |
| BALE DEMENSION | L1000*W1000*H650mm | L1300*W1100*H830mm | L1300*W1100*H830mm | L1300*W1100*H830mm | L1300*W1100*H1250mm |
| FEEDING | L1000*W1000mm | L1200*W1070mm | L1200*W1070mm | L1200*W1070mm | L1200*W1070mm |
| MACHINE DEMENSION | L6250*W1400*H2200mm | L6500*W1460*H2400mm | L6800*W1460*H2400mm | L6800*W1530*H2400mm | L7000*W1530*H2400mm |
| SLIDING PLATE (OPTION) | L3000*W1200*H150mm | L3000*W1200*H150mm | L3000*W1200*H150mm | L3000*W1200*H150mm | L3000*W1200*H150mm |
| NOISE | 80dB | 80dB | 80dB | 80dB | 80dB |
| COOLER MOTOR POWER | 0.75kw | 0.75kw | 0.75kw | 0.75kw | 0.75kw |
| MACHINE WEIGHT | about8000kg | about10000kg | about11000kg | about13000kg | about18000kg |
| WORKING EFFICIENCY | 1200-1600kg/hour | 1600-2000kg/hour | 2000-3000kg/hour | 3000-4000kg/hour | 5000-6000kg/hour |
| OIL TANK | 1000L | 1200L | 1200L | 1200L | 1400L |
| BALE DENSITY | 400-450kg/m3 | 450-480kg/m3 | 480-520kg/m3 | 520-580kg/m3 | 580-650kg/m3 |
For more products,please click into: http://gz-green.en.china.cn/productlist.html
