Specifications
1.SMPS battery charger2.Multi protections
3.Life Expectancy: 50,000H at 25 Degree
4.elegant,reliable
5. CE ROHS
Specifications:
size |
344*165*120mm |
net weight |
6.5kg |
max output power |
1500W |
certfication |
CE RoHS |
Features:
1. Full automatic,predict,CC,CV,CP,Segmented timing, A variety of charging mode selection. Communication with BMS. .
2. Precise limit of voltage¤t,guarantee full charged and avoid over charger.
3. Over current, over voltage, short circuit, reverse connect protection, overheating protection, safe and reliable
4. LED display, Aluminum shell, beautiful and strong, Vehicle shock, waterproof grade:IP46
5. Active power factor correction PFC, conversion efficiency > 99%, can realize zero pollution to power network, avoid big current impact on power grid.
6. Intelligent temperature compensation, can avoid lead-acid battery charging process appear overcharge or owe charge causes damage. Can greatly prolong the life of battery.
7.all kinds of production has passed the CE certification. 8.Efficiency: ≥88 %( full capacity)
Looking for a good quality charger with reasonable price ?
contact Alisa Han Now !!!
Jinan E-Shine Electronics Co., Ltd.
Tel:+86 15624552285
Skype:e-shinealisa
Operate Condition:
1.Temperature: -10~45 Degree
2.Hi-pot: ≥AC1500 (P to S),≥AC1500 (P to FG)
3.Life Expectancy: 50,000H at 25 Degree
Apply to:
1. Electrical forklift
2. Electrical motorcycle
3. Electrical tourist-car
48V60V72V96V High Standard Waterproof Electric Motor Boat Battery Charger
ESF-1800W(waterproof)Battery charger datasheet | |||||||||
|
No. |
ESF |
Constant voltage |
Constant Current |
Conversion/Cut off |
Weight |
Size |
|||
LA |
Li-Mn |
LiFePo4 |
(Max)A |
LA (A) |
Li(A) |
(kg) |
(mm) |
||
1 |
ESF24 |
29.4V |
29.4V |
29.2V |
50 |
10.0 |
5.0 |
6.5 |
344*165*120 |
2 |
ESF36 |
44.1V |
42.0V |
43.8V |
40 |
80. |
4.0 |
||
3 |
ESF48 |
58.8V |
54.6V |
58.4V |
30 |
6.0 |
3.0 |
||
4 |
ESF60 |
73.5V |
67.2V |
73.0V |
25 |
5.0 |
2.5 |
||
5 |
ESF72 |
88.2V |
84V |
87.6V |
20 |
4.0 |
2.0 |
||
1 |
Full automatic,predict,CC,CV,CP,Segmented timing, A variety of charging mode selection. Communication with BMS. |
||||||||
2 |
Precise limit of voltage¤t,guarantee full charged and avoid over charger. |
||||||||
3 |
Over current, over voltage, short circuit, reverse connect protection, overheating protection, safe and reliable |
||||||||
4 |
LED display, Aluminum shell, beautiful and strong, Vehicle shock, waterproof grade:IP46 |
||||||||
5 |
Active power factor correction PFC, conversion efficiency > 99%, can realize zero pollution to power network, avoid big current impact on power grid. |
||||||||
6 |
Intelligent temperature compensation, can avoid lead-acid battery charging process appear overcharge or owe charge causes damage. Can greatly prolong the life of battery. |
||||||||
7 |
CE&RoHS certified,Safety and Hige Quanlity |
||||||||
Cut-off point Li battery is 5% of CC,and it can be set between 3%-10%. | |||||||||
48V60V72V96V High Standard Waterproof Electric Motor Boat Battery Charger
Detail show
