Security System Alarm for Mobile Phone/Tablet/Camera

Specifications

1.Can charge for display article
2.Remote Control and LED Flash
3.Aluminum alloy body
4.Size/Color:customed
5.phone security

Security System Alarm for Mobile Phone/Tablet/Camera



High Quality Cell Phone Security Display Holder,Mobile Display Holder,Mobile Phone Security



Product overview

Size	8x6x12cm
Battery	5V lithium battery build-in
Adaptor	Dc 5V
Battery stand-by	2months
Alarn Volume	85-105Db
Charging	For 5V products
Color	Black/White

  Solutions                                                                        Applications

     1.Mechanical                                              1.Retails stores

     2.Electronic                                                 2.Offices

     3.Hybrid                                                       3.Trade shows

                                                                                                   4.Exhibits   5.Car Dealerships





Introduction:

1)Prevent your display articles from stealing.
2)It's convenient for the customers to see mobile phone,camera,laptop,MP4 or MP3 in exclusive shops etc.
3)With the connection of the article to the display shelf, security display holder can be realized while it is removed.

4)When it connects to display articles it can charge for them



Alarm Funtion:

1.Break or short circuit resistacne,it will alarm

2.Pry and cut spring wire ,it will alarm

3.Remove the sensor, it will alarm

4.Pull out the connector ,it will alarm.



 Features:



1.Quick Reaction speed, pull or cut the USB cable, the Alarm warning.



Once the alarm has been triggered, restitution cannot disarm, the alarm must be reset by remote control “OFF” key to disarm (press remote control “OFF” key to relief).



2. With high safety factor, it can protect customer’s property.



3.Built-in alarm horn, high-volume alarm on the bottom, can avoid destruction of the thief.



4.With Remote Control function, easy to use.



5.LED light display current status.



6.Wide range Application: retail chain store or exhibition center for Tablet PC, Camera, Smart Phone, GPS and other exhibits anti-theft and reusable .



Operating Step



1. Power ON/OFF Slide Switch: Please turn power ON before setting (on the bottom).



2. Tear off 3M stickers on the bottom, and stick MX-33P metal bottom on display desk.



3. Tear off 3M sticker (on Magnetic sensor) and stick on rear side Smart Phone.



4. Tear off 3M sticker on the Demo-Alert (small detecting sensor), and stick on Smart Phone (front or rear side surface).



5.Set up Demo-Alert in Active position: press ON button on Remote Control; you'll hear a beep sound and Red LED blinking (one time), the MX-33P in Active position.



6. Demo-Alert Sensor: 3 detecting sensors and phone jack connector are detect point, either one of detecting sensor Slip or phone jack disconnecting (active position), Alarm warning immediately and Blue LED blinking until alarm relief.



7. Relief alarm: press Remote Control OFF button to relief alarm warning and hear horn alarm.



8. Active Display Charge: the stand provide charge function, when Smart Phone battery low, you can plug charge cable between Smart Phone (Micro USB port) and Magnetic connector (a black hole at left side Magnetic connector), or direct charge from Adaptor to Smart Phone.



9. Low Power Indicator: when green LED light blinking, please plug USB port into to AC adaptor, mini USB plug into left side Demo-Alert metal base, then AC adaptor plug into Outlet (please avoid battery dried-up).



10. Working Period (in Active): 2 weeks (full charge).



11. Charge Time: 5 hours.



12. Low Power: Green LED blinking until power dried-up or charge.



13. Charging: Red LED turns ON.



14. Full Charge: Green LED turn ON.



15. Alarm: Red LED Blinking.



16. In Active (when you set up Alarm): Blue LED Blinking.



17. Remote Control: 5 units with one remote control.

Cell phone/ mobile display holder
Independent chargable security alarm display stand holder
Phone Display anti-theft display holder alarm

Certificate
