Specifications
1.Cable Sensor Mobile Phone Security Alarm2.Aluminum alloy
3.White Color
4. 7.5*5*10 CM
5.CE,ISO,ROHS
Product Picture
Product Description
1. This secure display alarm is widely used in the digital products stores, the supermarket open shelves for
cell phone samples and trade Show ,it Prevent your displaying electronics from stealing.
2. Security display alarm stand -FC160B is design for Mobile Phones.It Security Alarm Micro USB Hub Phone Holder For SamSung can protect the real goods when
they are on sales instead of the model.
3. Allow your customer to touch it freely and browse it for the function.To increase your amount of browse
as well as the sales amount.
4.Beautiful desigh,can upgrade your merchandise.to make your merchandise different from others .
Product Information
Production name: Cable Sensor Mobile Phone Security Alarm
Operating Voltage |
5V DC |
Horn Alarm Output |
≤120 db at 1 ft |
Stand-by Current Consumption |
≤3.70mA |
Quiescent Current Consumption |
≤3.40mA |
Activation Current Consumption |
≤220mA |
Metal Display Frame Color |
Black/White |
Battery |
Lithium-ion battery |
the charging function |
You can charge the 5V digital products output. |
Set up defences: |
Remote control |
Product Feature
1) Quick Reaction speed, pull or cut the USB cable, the Alarm warning.
2) Once the alarm has been triggered, restitution cannot disarm, the alarm must be reset by remote control “OFF” key to disarm (press remote control “OFF” key to relief). With high safety factor, it can protect customer’s property.
3) Built-in alarm horn, high-volume alarm on the bottom, can avoid destruction of the thief.
4) With Remote Control function, easy to use.
5) LED light display current status.
6) Wide range Application: retail chain store or exhibition center for Tablet PC, Camera, Smart Phone, GPS and other exhibits anti-theft and reusable .
Product Operation
1) Power ON/OFF Slide Switch: Please turn power ON before setting (on the bottom).
2) Tear off 3M stickers on the bottom, and stick MX-33P metal bottom on display desk.
3) Tear off 3M sticker (on Magnetic sensor) and stick on rear side Smart Phone.
4) Tear off 3M sticker on the Demo-Alert (small detecting sensor), and stick on Smart Phone (front or rear side surface).
5) Set up Demo-Alert in Active position: press ON button on Remote Control; you'll hear a beep sound and Red LED blinking (one time), the MX-33P in Active position.
6) Demo-Alert Sensor: 3 detecting sensors and phone jack connector are detect point, either one of detecting sensor Slip or phone jack disconnecting (active position), Alarm warning immediately and Blue LED blinking until alarm relief.
7) Relief alarm: press Remote Control OFF button to relief alarm warning and hear horn alarm.
8) Active Display Charge: the MX-33P provide charge function, when Smart Phone battery low, you can plug charge cable between Smart Phone (Micro USB port) and Magnetic connector (a black hole at left side Magnetic connector), or direct charge from Adaptor to Smart Phone.
9) Low Power Indicator: when green LED light blinking, please plug USB port into to AC adaptor, mini USB plug into left side Demo-Alert metal base, then AC adaptor plug into Outlet (please avoid battery dried-up). 10) Working Period (in Active): 2 weeks (full charge).
11) Charge Time: 5 hours.
12) Low Power: Green LED blinking until power dried-up or charge.
13) Charging: Red LED turns ON.
14) Full Charge: Green LED turn ON.
15) Alarm: Red LED Blinking.
16) In Active (when you set up Alarm): Blue LED Blinking.
17) Remote Control: 5 units with one remote control.
Product Packing
1) series (Remote Control Demo-Alert).
2) Universal USB Adaptor 5Vdc / 500mA.
3) Infrared Remote Control.
4) USB to mini USB Cable.
5) Magnetic Detecting Sensor Cable.
6) Micro USB to 3.5Φcharge cable.
About us
Versatile protection technology
(1) Remove FC160B base---It alarm
(2) Remove the sensor---It alarm
(3) Remove the bracket---It alarm
(4) Cut the lanyard---It alarm
Product Deatail
Primary Competitive Advantages
Brand-name Parts: Fratcrl
Packaging :Standard Export Ctns
Quality Approvals :each product will be checked by QA before send goods.
Price :Wholesale Price
Reputation :Famous
Product Features :security and alarm
Service :The Guarantee period is 14 months since the goods delivered
Product Performance :for Mobile Phone Security and Alarm
