Haptime Usb Mobile Phone Security With Charge Function

Shenzhen Farctrl Technology Co., Ltd.
Haptime Usb Mobile Phone Security With Charge Function thumbnail-1
Haptime Usb Mobile Phone Security With Charge Function photo-1
US$ 20 - 30 MOQ: 20 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
FARCTRL
Model Number:
FC160F
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name FARCTRL
Model Number FC160F
Charger Yes
Compatible Brand Other, it suit all phones
Material ABS

Specifications

1.haptime usb mobile phone security with charge function 2.material:ABS
3.host size:4*1*1cm
4.white or black
5.CE,ISO

haptime usb mobile phone security with charge function



description: This alarm system is designed for mobile phones, It prevent your display articles from stealing. It's convenient for the customers to see mobile phone in exclusive shops and exhibitions. With the connection of the article to the display shelf, security display holder can be realized while it is removed.
When it links to the display articles it can charge for them.



haptime usb mobile phone security with charge function







Basic Specification

Operating Voltage5V DC
Horn Alarm Output≤120 db at 1 ft
Stand-by Current Consumption≤3.70mA
Quiescent Current Consumption≤3.40mA
Activation Current Consumption≤220mA
Metal Display Frame ColorBlack/White
BatteryLithium-ion battery
the charging functionYou can charge the 5V digital products output.
Set up defences: Remote control

Function:
  1. A disconnect alarm function: contacts separated alarm, disconnect alarm, USB jack unplug alarm.
  2. Fortification solution and Defense: auto fortification; solution of anti-manually or remote control anti-solution.
  3. Remote control: Infrared remote control ON (Active) / OFF.
Features:
  1. Quick Reaction speed, pull or cut the USB cable, the Alarm warning.
  2. Once the alarm has been triggered, restitution cannot disarm, the alarm must be reset by remote control “OFF” key to disarm (press remote control “OFF” key to relief). With high safety factor, it can protect customer’s property.
  3. Built-in alarm horn, high-volume alarm on the bottom, can avoid destruction of the thief.
  4. With Remote Control function, easy to use.
  5. LED light display current status.
  6. Wide range Application: retail chain store or exhibition center for Tablet PC, Camera, Smart Phone, GPS and other exhibits anti-theft and reusable .
Operating Step:
  1. Power ON/OFF Slide Switch: Please turn power ON before setting (on the bottom).
  2. Tear off 3M stickers on the bottom, and stick MX-33P metal bottom on display desk.
  3. Tear off 3M sticker (on Magnetic sensor) and stick on rear side Smart Phone.
  4. Tear off 3M sticker on the Demo-Alert (small detecting sensor), and stick on Smart Phone (front or rear side surface).
  5. Set up Demo-Alert in Active position: press ON button on Remote Control; you'll hear a beep sound and Red LED blinking (one time), the MX-33P in Active position.
  6. Demo-Alert Sensor: 3 detecting sensors and phone jack connector are detect point, either one of detecting sensor Slip or phone jack disconnecting (active position), Alarm warning immediately and Blue LED blinking until alarm relief.
  7. Relief alarm: press Remote Control OFF button to relief alarm warning and hear horn alarm.
  8. Active Display Charge: the MX-33P provide charge function, when Smart Phone battery low, you can plug charge cable between Smart Phone (Micro USB port) and Magnetic connector (a black hole at left side Magnetic connector), or direct charge from Adaptor to Smart Phone.
  9. Low Power Indicator: when green LED light blinking, please plug USB port into to AC adaptor, mini USB plug into left side Demo-Alert metal base, then AC adaptor plug into Outlet (please avoid battery dried-up).
  10. Working Period (in Active): 2 weeks (full charge).
  11. Charge Time: 5 hours.
  12. Low Power: Green LED blinking until power dried-up or charge.
  13. Charging: Red LED turns ON.
  14. Full Charge: Green LED turn ON.
  15. Alarm: Red LED Blinking.
  16. In Active (when you set up Alarm): Blue LED Blinking.
  17. Remote Control: 5 units with one remote control.

alarm reaction as following ways:

break circuit resistance
short circuit resistacne
other circuit-replacing resistacne
cut the resistance
prying and cutting spring wire
remove the sensor
pull out connector



haptime usb mobile phone security with charge function



haptime usb mobile phone security with charge function



haptime usb mobile phone security with charge function
