110V or 220V AC 48V DC Lead acid Battery Charger for Electric Cleaning Machine

Specifications

1.SMPS battery charger
2.Multi protections
3.Life Expectancy: 50,000H at 25 Degree
4.elegant,reliable
5. CE ROHS

Specifications:



size	230*135*70mm
net weight	3.0kg
max output power	900W
certfication	CE



 Features:

1.short-circuit protection,charger o/p current automatically when short-circuit.

2.overload protection:charger o/p current limited automatically when overload.    3.reverse polarity protection:it will shut down when the wire is connected,charge DC fuse or remove the fault.

4.3-stage charging mode: CC(constant current), CV(constant voltage) and float stage.

5. Reliable, elegant,Small size, light,

6.charging state:two LED display.

7.all kinds of production has passed the CE certification.

8.Efficiency: ≥88 %( full capacity)

Operate Condition:

    1.Temperature: -10~45 Degree



    2.Hi-pot: ≥AC1500 (P to S),≥AC1500 (P to FG)



    3.Life Expectancy: 50,000H at 25 Degree

110V or 220V AC 48V DC Lead acid Battery Charger for Electric Cleaning Machine

Apply to:



   1. Electrical forklift



   2. Electrical motorcycle



   3. Electrical tourist-car

Package:

There is product name, model, name of manufacturer, safety approval, serial number, User Manual and packing

list in the package box.

Reliability requirements:

MTBF (standard, environmental temperature, load requirement) ≥50K hours;

testing condition: 25℃,full load, testing proved value.

Looking for a good quality charger with reasonable price ?
contact Alisa Han Now !!!
Jinan E-Shine Electronics Co., Ltd.
Tel:+86 15624552285
Skype:e-shinealisa

Storage:

Products should be stored in package box when it is not used. And warehouse temperature should be -40~70℃, and relative humidity is 5~95%. In the warehouse, there should not be harmful gas, inflammable,

explosive products, and corrosive chemical products, and strong mechanical vibration, shock and strong magnetic

field affection. The package box should be above ground at least 20cm height, and 50cm away from wall, thermal

source, and vent. Under this requirement, product has 2 years of storage period, and should be rechecked when over 2 years.





110V or 220V AC 48V DC Lead acid Battery Charger for Electric Cleaning Machine

Detail show:
