Specifications
1.Good quality and price competitive2.Through color
3.Durable (more than 30 years)Impact resistant
4.Low maintenance
1.Calcium silicate board
Woersen board is a kind of new model construction board known for its stable quality, the method is using silicate material and calcium material,adding strengthened fiber and other advanced process, a high technology product by high temperature high pressure braize and drying treatment.It is widely used in office building,school,shop ,dwelling,railway,railway station ,bus station,airport,scientific organization ,restaurant,hospital,cinema,badminton ,training building,KTV ,etc building
1.Application
1.The applicaiton purpose for this panel is for outdoor Cladding or Facade.
2.Cladboard is the panel which can be used for exterior in all weather. It can stand severe cold as well as hot weather.
To be used as a finished exterior cladding panel, it can be coated before installation but it is up to client's applicaiton design. You can precoat it in difference colors with our off white panel or use the offwhite panels directly or we can deliver the boards finished in 3 kinds of colour board: Grey, Red and Yellow.
3.Cladboard can be used to concrete wall or infill wall.
2.Specification
4-25* 1220 *2440Tolerance in Dimension
Item |
index |
Requirement |
Length |
<1200 |
±3 |
|
1200~2400 |
±4 |
|
>2400 |
±5 |
Width |
≤1200 |
±3 |
|
>1200 |
±4 |
Thinckness |
≤9 |
±0.3 |
|
9~15 |
±0.5 |
|
>15 |
±0.6 |
3.Physical properties
The following data are the average tested figures during manufacturing.
Item |
Index |
Unit |
Density |
0.9-1.2 or 1.2-1.4 |
g/cm3 |
Thermal Conductivity |
0.29,0.2 |
W/(m·k) |
Water Absorption |
≤28 |
% |
Water Contain |
≤10 |
% |
Moisture Movement |
≤0.25 |
% |
Freezing |
Non-delaminating and rimous |
25times cycle |
Non-water soaking |
No water formed |
24 h |
Non-combustibility |
GB 8624 :1997 Class A |
/ |
Bending Strength |
≥16 |
MPa |
REMARK: Please contact our technical department if you need more technical index. | ||
4.Installation methods:
1. We draw the installation guideline to define the fixing position, the center distance is 1200mm.
2. USe UC type keel hang fitting to link and fix the room and key keel, keep the key keel horizontal.
3. Use the caliper to vertically fix the sub keel on key keel,the center distance of the sub keels is 611mm.
4. TO install the horizontal keels as per the request,is center distance is 1222mm.
5. Use the tapping screw fix the woersen board on the sub-keel and do the treatment of the seam connection.
Any question you have,Please contact me without any hesitate.
Best regards,
Daicy chen
