VRLA UPS battery 12V 18AH
Detail Specifications:
| Nominal Voltage | 12V | |
| Rated capacity(20 hour rate) | 18AH | |
| Dimensions | Length | 181±1mm(7.13 inches) |
| Width | 76±1mm(3.03inches) | |
| Height | 167±1mm(6.57inches) | |
| Total Height | 167±1mm(6.57inches) | |
| Weight Approx | 5.20Kg(11.46 lbs) | |
| Capacity 25°C(77°F) | 20 hour rate(0.85A, 10.50V) | 18.0AH | |
| 10 hour rate(1.66A, 10.50V) | 16.6AH | ||
| 5 hour rate(2.89A, 10.50V) | 14.45AH | ||
| 1 hour rate(10,2A, 9.60V) | 10.2AH | ||
| Internal Resistance | Full charged Battery at 25 °C (77°F) |
17m | |
| Capacity affected by temperature (20 hour rate) |
40°C(104°F) | 102% | |
| 25°C(77°F) | 100% | ||
| 0°C(32°F) | 85% | ||
| -15°C(5°F) | 65% | ||
| Self-Discharge at 25°C(77°F) |
Capacity after 3 month storage | 91% | |
| Capacity after 6 month storage | 82% | ||
| Capacity after 12 month storage | 64% | ||
| Charge (constant voltage) |
Cycle | Initial Charging Currentless than 5.40A Voltage14.40-15.00 V | |
| Float | Voltage 13.50-13.80V | ||
| Terminal | T3,T13 | ||
Main Features:
1.Low selfdischarge: lower than 3% of rated capacity per month under normal operating temperature
2.ABS case (can be made with flame retardant V0)
3.No memory effect after repetitious usage or discharges
4.Maintenance-free operation
5.Sealed construction and leak proof
6.Safety valve regulated system
7.Operating in any position
8.Deep discharge recovery
9.Wide operating temperature range
Applications:
1.Telephone switchboards, electric equipments, medical equipments, medical instruments
2.Computers and uninterrupted power source (UPS)
3.Power transmission and transformer station, switch control and accident lighting
4.Fire fighting, safety device and alarm monitoring
5.Aviation, spaceflight and power storage
6.Automatic office system
7.Radio communication system
8.Emergency lighting and car and ship starting system
9.Portable electric appliances and mining system
Type :12v UPS Battery:
1.Material : high quality lead, spongy lead, AGMseparator , pure sulphuric acid.
2.long life span and super design
3.Warranty : 12 -15 months
4.Delivery:within 15~30days after receiving deposit.
5.Packing:4pcs/cartons, with or without pallet.
6.OEM: customer's brands & packaging design/dimension for free.
Certifications
We are ISO9001 verified factories. From material to finished poducts. Every procedure are strictly managed accordance with this quality stardard, to ensure the good quality supply to customers.
Why Choose Us
1.door to door service.
2.low cost raw material with high quality.
3.Independent designer with more than 10 years design experience.
duct with the international market step.
5.our products are exported to Middle East,Europe,Asia,America,south Africa and else.
6.we would like stand with you in same line to open market with long term business.
