Home > Products > Battery for European Market > 12v 17ah battery for mobility scooter
12v 17ah battery for mobility scooter
- 80000 Piece / Pieces per Month
- guangzhou
- T/T L/C D/P D/A Credit Card PayPal
- Passenger 3 wheels motorcycle batteries ,12V18Ah three wheel bike battery
- motorcycle batteries battery 12v 18ah
- best price lead acid motorcycle rechargeable battery 12v 18ah
- 12v 18ah motorcycle battery 12v lead acid motorcycle battery motorcycle battery parts
- 12v 18ah high performance dry charged motorcycle battery
- 12N18-3A 12V 18Ah motorcycle battery
Product Details
Place of Origin: | China | Brand Name: | Matrix | Model Number: | NP17-12 |
Usage: | Other, UPS, solar systerm,stationary battery, UPS, Solar system, Back up | Voltage: | Other, 12v | Sealed Type: | Sealed |
Maintenance Type: | Free | Size: | 181*76*167mm | Weight: | 5.4kg |
Nominal Capacity: | 17ah |
Product Description
12v 17ah battery for mobility scooter
Details of battery for mobility scooter
1.Size:331*175*216mm
2.Weight:33kg
3.Norminal Voltage:12v
4.Norminal Capacity:100ah
5.Terminal:T5/T9
6.Life time:3 to 5 years
12v 17ah lead-acid storage batteries Features:
1. Positive and negative plates consist of active mass and a lead-calciumalloy grid structure
2. Safty Valve The safety valve opens when there is an abnormal increases in internal pressure caused by overcharging or misusage. Gas is released from the battery to return the pressure back to norminal.
3. Container and Coverstteries
Container and covers are made of ABS or PP resin, with superior strength and acid resistance characteristics. The container and covers are sealed to prevent electrolyte and gas leakage.
4. Other parts Some other parts of this moodel, like terminal, case, terminal protector, electrolyte.Active materials are in good quality. You can check the quality by sample.
Advantage of 12v 17ah lead-acid storage batteries
1.The battery is full of power when it’s out of factory, no need to add liquid to charge;
2.No memory, no need to discharge battery to use, suitable for circuit design;
3.Use high class separator plate, adsorption function is very strong;
4.There is no flowing liquid (poor liquid), does not leak acid and free Upside down,
5.Comply with environmental requirements, ease of use,
6.The use of lead-calcium alloys, battery self-discharge is very low,
7.Easy storage, less maintenance;
8.Using ABS plastic shell and valve technology for safe use.
Notice of 12v 17ah lead-acid storage batteries
1 Don’t near the hot source and don’t under the sunshine.
2 Don’t charge in the sealed container.
3 No short circuit. It should be addition charge if you don’t use, and single charge per three months, to avoid irreversible sulfating. The battery should be changed when the battery jar broken or the electrolyte omitted, to avoid acid corrosion.
4 Don’t store in the space of acid gas.
You should be careful and regular check when use the battery. To avoid the battery don’t work. You should change the battery if the capacity is not full or has been damage, especially after one
Specification of 12v 17ah lead-acid storage batteries
Capacity 25°C(77°F) | 20 hour rate(0.85A, 10.50V) | 17.0AH | |
10 hour rate(1.56A, 10.50V) | 15.6AH | ||
5 hour rate(2.89A, 10.50V) | 14.45AH | ||
1 hour rate(10,2A, 9.60V) | 10.2AH | ||
Internal Resistance | Full charged Battery at 25 °C (77°F) | 17mΩ | |
Capacity affected by temperature (20 hour rate) | 40°C(104°F) | 102% | |
25°C(77°F) | 100% | ||
0°C(32°F) | 85% | ||
-15°C(5°F) | 65% | ||
Self-Discharge at 25°C(77°F) | Capacity after 3 month storage | 91% | |
Capacity after 6 month storage | 82% | ||
Capacity after 12 month storage | 64% | ||
Charge (constant voltage) | Cycle | Initial Charging Currentless than 5.10A Voltage14.40-15.00 V | |
Float | Voltage 13.50-13.80V | ||
Terminal | T3,T13 |
Characteristic 12v 17ah lead-acid storage batteries
Nominal Voltage | 12V | |
Rated capacity(20 hour rate) | 17AH | |
Dimensions | Length | 181±1mm(7.13 inches) |
Width | 76±1mm(3.03inches) | |
Height | 167±1mm(6.57inches) | |
Total Height | 167±1mm(6.57inches) | |
Weight Approx | 5.40Kg(11.46 lbs) |
