This machine is suitable for 2-500g material circular flat plastic or glass bottles of powder filling capping. This machine is made of high precision cam indexing mechanism to provide indexing equal-dividing disk positioning plug cover; acceleration cam drive provides capping head lifting; constant torque capping; high precision screw metering filling; without touch screen control. Bottle filling, without inner plug, the outer cover. With accurate positioning, stable transmission, protective cap, accurate in measurement. The advantages of simple operation, fully in line with the new GMP requirements of the national.
Characteristic:
Computer control, accurate, convenient operation of installed capacity.
The engine speed can be stepless variable speed.
Production of automatic quantitative control.
Multiple fault prompting function.
Automatic shutdown function, appear continuously without filling cases can be automatically shut down.
The appearance of the use of SUS304 stainless steel easy maintenance.
316L stainless steel screw filling, corrosion resistance strong.
This equipment is in full compliance with the new GMP requirements
Technical parameters:
Applicable specifications :2-500g
Production capacity :20-50 bottle / min
Filling precision is less than or equal to :+ 1%
Power :220V / 50Hz
Rotary ( rolling ) cover rate of more than 99%
Automatic plug rate :> 99%
Gas :1.3 m3 / h 0.4-0.8Mpa
Power :2 kW
Machine net weight :500kg
Size : 2200 * 1000 * 1600mm
1.Installation & adjustment
After the equipment are arrived at the customer’s site, the customer is responsible for unpacking and arranging the equipment according to the placement drawing; and does under our install-adjust technicians’ guidance. Costs of the staff are decided at last.
2.Training
We are responsible for offering the technical training to user. The training content includes the structure and maintenance of the equipment, control and operation of the equipment. Through training, users' technical staff can grasp and the skill of operation and maintenance proficiently, and deal with the general troubles in time. We will appoint qualified technical staff for the guidance.
3.Quality assurance
We guarantee the line achieve product technical performance indicators within 5 days after feeding operation through the correct guidance of the installation and commissioning.
We are responsible for the fault and damage of the production line caused by our design, technology, manufacture, installation, adjustment and material defect etc. that all belong to our responsibility.
The warranty period is 12 months after acceptance check of the production line. If there is any different between the furnished equipment in the customer’s factory and the equipment concerned in the contract, the users have the right to pass the inspection book to the legal department to claim for compensation to our company within goods warranty period.
4.Warranty
Offer 12 months maintenance period to the problem that caused by our design, manufacture and the material quality, and offer the relevant parts and effective service for free for above reason. We will offer a widely and favorable technical support, after service all the time after guarantee period.
