Printing Paper RFID Sticker Used for Assets Managment

Printing Paper RFID Sticker Used for Assets Managment photo-1
US$ 0.1 - 0.35 MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
HY printing paper RFID sticker
Model Number:
printing paper RFID sticker
Payment & Shipping
Payment Methods:
Port of Shipment:
Jinan
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name HY printing paper RFID sticker
Model Number printing paper RFID sticker

Specifications

printing paper RFID sticker
&used for assets managment printing paper RFID sticker
&accept paypal for trial order
&factory

printing paper RFID sticker used for assets managment



printing paper RFID sticker
&used for assets managment printing paper RFID sticker
&accept paypal for trial order
&factory



printing paper RFID sticker Description:

  • Adopt Frequency Hopping working mode, with strong anti-jamming ability.
  • User can define the reading& writing of standard data, to make their special application system more efficient.
  • The effective reading distance can reach up to 8m (up to read and antenna). With 1024 writable user area (ISO18000-6B protocol) and 512 bits writable user area (EPC Gen2 protocol) .
  • With ultra-wide working frequency design. Meet the relevant industry regulations, and is suitable for flexible application development.
  • It can read and write multi-tags (up to 50pcs/s ), and is not affected or restricted by tag quantity in the working area.
  • 1960 bits memory area for user to read, write and re-write. With permanent special area for appointed user.
  • Passive type, with no battery. The memory area is re-writable for more than 100,000 times. The useful life can be 10 years above, so it’s very cost-effective.

printing paper RFID sticker Specifications



Protocol

ISO18000-6B, ISO18000-6C (EPC GEN2)

Frequency Range

ISM 902~928MHz (FCC), ISM865~868MHz (CE)

 Working Mode

Fixed Frequency or FHSS, Software Programmable

Memory Capacity

MR6740A tag supports ISO18000-6B protocol, with 1024 bits (128 bytes) writable user area;

MR6740B tag supports EPC GEN2 (ISO18000-6C), with 96bits writable EPC Code area, and 512 bits writable user area.

Reading Rate

Software Programmable.  Average Reading per 64Bits: <10ms

Tags Material

Paper material, tamper-proof

Reading Range

>12 m maxium, determined by reader and antenna

Operation Temp

-20°C~+80°C



printing paper RFID sticker Example illustration

printing paper RFID sticker used for assets managment

printing paper RFID sticker pictures



printing paper RFID sticker used for assets managment





printing paper RFID sticker used for assets managment





printing paper RFID sticker used for assets managment



printing paper RFID sticker used for assets managment
